Eaton JJN-30 Fuse - Class T, 30 A, 20 kAIC at 160 Vdc
Part Number: JJN-30
Quick Summary
The Eaton JJN-30 fuse is a current-limiting device designed for motor drives and VFD line protection. Engineers often struggle with nuisance trips and undersized protection when wiring variable-speed drives. CE marking and RoHS compliance ensure regulatory alignment, while Class T fast-acting protection suits demanding loads. Combined with ferrule-end connections and standard packaging, the JJN-30 delivers reliable protection with straightforward installation. This enables shorter downtime and simpler inventory management for panel builders and end users. With a 30 A rating and high interrupt capabilities, it protects VFD lines against fault currents without excessive nuisance tripping. This combination translates into predictable performance, safer equipment, and improved maintenance planning.
Product Information
Extended Description
JJN-30 Eaton: Eaton Bussmann series JJN fuse, Current-limiting, VFD line protection, 30 A, Class T, Non-indicating, Ferrule end x ferrule end, 20 kAIC at 160 Vdc, 200 kAIC at 300 V, Standard, 10, 300 V, 160 Vdc
Product Name
Eaton Bussmann series JJN fuse
Catalog Number
JJN-30
UPC
051712627009
EAN
5027590508674
Product Length/Depth
0.42 in
Product Height
0.87 in
Product Width
0.42 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
30 A
Interrupt rating
20 kAIC at 160 Vdc 200 kAIC at 300 Vac
Voltage rating
300 Vac, 160 Vdc
Packaging type
Standard
Class
Class T
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Quantity
10
