Eaton KAC-1 high speed fuse - UL Recognized
Part Number: KAC-1
Quick Summary
KAC-1 high speed fuse protects electrical circuits with rapid interruption for control panels and motor drives. Engineers often struggle with nuisance trips from slower fuses and arc damage during short, high-energy faults; this solution minimizes outages while safeguarding sensitive loads. UL Recognized and CE Marked status, combined with a 200 kAIC interrupt rating, support global compliance across critical applications. The non-indicating design paired with blade-end x blade-end connections and stud mounting delivers flexible installation in compact spaces, aligning with Bussmann series practices. For panel builders and maintenance teams, KAC-1 provides reliable protection without complicating field wiring or inventory requirements, while enabling scalable protection strategies across equipment fleets.
Product Information
Extended Description
KAC-1 Eaton: Eaton Bussmann series Tron KAC high speed fuse, 1A, 200 kAIC, Non Indicating, High speed fuse, Blade end X blade end, Stud
Product Name
Eaton Bussmann series Tron KAC high speed fuse
Catalog Number
KAC-1
UPC
051712470018
Product Length/Depth
0.5 in
Product Height
2.84 in
Product Width
0.5 in
Product Weight
0.4 lb
Warranty
Not Applicable
Compliances
CE Marked
Certifications
UL Recognized
Amperage Rating
1 A
Interrupt rating
200 kAIC
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Mounting method
Stud
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - KAC-1
Feature → Business Impact → Application: 1 A amperage rating paired with a 200 kAIC interrupt rating delivers fast fault clearance, reducing downtime and limiting damage to downstream components in motor control circuits and power-distribution panels. Application: ideal for compact control panels and feeder circuits where space is at a premium and quick isolation is critical. Feature → Compatibility and installation ease → Application: blade end x blade end with stud mounting simplifies cabinet integration, enabling quick swaps in rugged industrial environments and reducing commissioning time. Feature → Non-indicating design → Application: removes visual indicators that can complicate space planning in densely populated enclosures, supporting clean wiring layouts and easier risk assessment. Feature → Certifications and compliance → Application: CE Marked and UL Recognized ensure adherence to global electrical safety standards, enabling cross-border deployments in manufacturing lines and process plants. Feature → Mechanical footprint and weight → Application: 0.5 in width and depth, 2.84 in height, and 0.4 lb weight yield a compact profile suitable for tight panel spaces and standardized tray mounting, improving inventory planning and logistically efficient installations. Feature → Industry context and reliability → Application: Eaton Bussmann Tron KAC fuses are designed for high-reliability protection in automation and electrical protection & circuit control sectors, supporting preventative maintenance programs and total cost of ownership reduction.
Get a Quick Quote for a Eaton KAC-1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KAC-1?
Enquire Now
FAQs
The KAC-1 uses blade-end x blade-end connections with stud mounting, offering flexible mounting options in compact enclosures. Its 0.5 in width and 0.5 in depth help maximize panel footprint, while a 2.84 in height accommodates common DIN rail or tray layouts. This setup simplifies field replacement and reduces cabinet rework during upgrades.
KAC-1 is rated for 1 A and provides an interrupt rating of 200 kAIC, enabling fast fault clearance for small to medium circuits. The device is non-indicating, blade-end x blade-end, with stud mounting, making it suitable for motor drives, control panels, and feeder circuits that require high-speed protection and reliable isolation.
Yes. KAC-1 is CE Marked and UL Recognized, ensuring compatibility with European and North American safety standards. This combination supports cross-border deployments in manufacturing facilities and automation projects, helping maintain regulatory compliance while standardizing protection across sites.
By delivering rapid interruption at 200 kAIC, the KAC-1 minimizes arc energy and downstream damage, reducing repair times and outages. Its compact form factor lowers panel space costs, while UL/CE compliance reduces regulatory risk. These factors collectively improve machine uptime and lower total cost of ownership for automation systems.
Official Eaton sources provide the KAC-1 datasheet and full Bussmann series catalogs. Key references include the Eaton Specification Sheet for KAC-1 and the Bussmann series catalog no. 1007, available as PDFs from Eaton's product pages and archival catalogs, which offer detailed electrical and mechanical specifications for procurement and engineering validation.
