Eaton KAC-225 High Speed Fuse - UL Recognized, 200 kAIC
Part Number: KAC-225
Quick Summary
The KAC-225 high speed fuse from Eaton protects DC bus rectifiers in industrial drives. Engineers wrestle with nuisance trips and slow fault isolation in high-current DC systems, and this device delivers rapid interruption to minimize downtime. It carries UL Recognized certification and CE marking, supporting safety compliance and reliable integration in global electrical installations. Designed for blade-end and stud mounting, it streamlines installation and reduces spare-parts variety across equipment lines. In procurement terms, the KAC-225 aligns with the Bussmann Tron family, ensuring compatibility with common blade and stud configurations and simplifying stocking. With a 225 A rating and 200 kAIC interrupt capacity, it protects expensive drives and rectifiers while helping maintenance teams plan preventive replacements.
Product Information
Extended Description
KAC-225 Eaton: Eaton Bussmann series Tron KAC high speed fuse, 225A, 200 kAIC, Non Indicating, High speed fuse, Blade end X blade end, Stud
Product Name
Eaton Bussmann series Tron KAC high speed fuse
Catalog Number
KAC-225
UPC
051712472258
Product Length/Depth
6.182 in
Product Height
6.1 in
Product Width
2.1 in
Product Weight
1.98 lb
Warranty
Not Applicable
Compliances
CE Marked
Certifications
UL Recognized
Amperage Rating
225 A
Interrupt rating
200 kAIC
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Mounting method
Stud
Feature: 225 A amperage rating with a 200 kAIC interrupt capacity provides rapid fault clearance. Business Impact: Protects expensive conductors and power electronics from surge currents, reducing damage and downtime. Application: Suited for rectifier banks, DC buses, and motor-drive power conversion equipment in heavy industry. Feature: Non Indicating fuse status. Business Impact: simplifies panel design and reduces maintenance cycles, while status is captured by the control system. Application: panels without onboard indicators or where remote signaling is used. Feature: Blade end x blade end connections with stud mounting. Business Impact: flexible integration into existing panel architectures and robust, vibration-resistant installation. Application: can replace legacy fuses in standard blade-stud configurations across switchgear. Feature: Compact yet robust dimensions—6.182 in length, 6.1 in height, 2.1 in width; weight 1.98 lb. Business Impact: saves panel space, reduces shipping weight, and facilitates handling during installation. Application: fits standard equipment footprints and allows easy stacking in cabinets. Feature: CE Marked and UL Recognized. Business Impact: compliance with global safety standards supports regulatory approvals and reduces risk during audits. Application: ideal for multinational facilities and OEMs requiring standard protection components.
Get a Quick Quote for a Eaton KAC-225
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KAC-225?
Enquire Now
FAQs
The KAC-225 is a high-speed fuse designed to protect DC bus rectifiers, power supplies, and motor-drive circuits in industrial panels. With a 225 A rating and 200 kAIC interrupt capability, it rapidly clears faults to minimize equipment damage and downtime. It uses blade-end x blade-end connections with a stud mounting option for flexible installation.
Yes. The KAC-225 carries UL Recognized certification and CE marking, confirming compliance with widely adopted safety standards. These approvals support regulatory acceptance in many regions, streamline panel approvals, and enable safer, certified integration into global electrical installations.
The KAC-225 supports blade end x blade end connections and a stud mounting method. This combination provides robust, vibration-resistant installations and compatibility with common enclosure layouts, simplifying retrofits and new builds alike while maintaining secure conductor termination.
Ideal for rectifier banks, DC buses, and power conversion equipment in industrial drives and switchgear. Its 225 A rating and 200 kAIC interrupt capability make it suitable for high-energy DC protection while maintaining compact footprint and ease of integration within Bussmann Tron family designs.
As a non-indicating fuse, the KAC-225 relies on system-level status signaling rather than an onboard indicator. Plan replacements based on ambient operating conditions and manufacturer guidance, and keep spares within standard Bussmann Tron catalog parts to ensure quick procurement and consistent protection across panels.
