Eaton KAC-3 High Speed Fuse - UL Recognized, 200 kAIC
Part Number: KAC-3
Quick Summary
The Eaton KAC-3 high speed fuse protects power electronics and control circuits in industrial drives and rectifier assemblies. Sizing correctly and avoiding nuisance trips is a common challenge that disrupts uptime and increases maintenance costs. UL Recognized and CE marked provide regulatory confidence, while a 200 kAIC interrupt rating ensures fast, safe fault clearing. As part of Eaton Bussmann’s Tron KAC family, it delivers reliable protection with a compact footprint that simplifies panel design. This translates to reduced downtime, lower energy waste, and safer, more predictable protection of critical power paths. The datasheet provides mounting, wiring, and fusing guidelines for consistent performance.
Product Information
Extended Description
KAC-3 Eaton: Eaton Bussmann series Tron KAC high speed fuse, 3A, 200 kAIC, Non Indicating, High speed fuse, Blade end X blade end, Stud
Product Name
Eaton Bussmann series Tron KAC high speed fuse
Catalog Number
KAC-3
UPC
051712470032
Product Length/Depth
0.5 in
Product Height
2.84 in
Product Width
0.5 in
Product Weight
0.4 lb
Warranty
Not Applicable
Compliances
CE Marked
Certifications
UL Recognized
Amperage Rating
3 A
Interrupt rating
200 kAIC
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Mounting method
Stud
Feature: 3 A amperage rating with a 200 kAIC interrupt rating. Business Impact: Enables fast fault clearing to minimize arc energy and protect downstream power electronics. Application: Ideal for rectifiers, small power supplies, and control circuits in industrial drives. Feature: Blade end x blade end connections with stud mounting and a compact footprint (0.5 in depth, 0.5 in width, 2.84 in height). Business Impact: Simplifies installation, reduces panel space needs, and improves mechanical reliability in tight control panels. Application: Suitable for panel boards, fuse holders, and compact electrical enclosures. Feature: UL Recognized and CE Marked. Business Impact: Enhances regulatory compliance and reduces qualification time for equipment. Application: Meets global safety standards for industrial equipment and OEM assemblies. Feature: Non Indicating fuse indicator. Business Impact: Lower cost and simpler replacement planning in systems with centralized status monitoring. Application: Works with remote fault indicators and control architectures. Feature: Weight 0.4 lb and standard packaging. Business Impact: Lightweight, easy handling during field installation and servicing. Application: Fits into standard shipping and inventory workflows for spare parts. Feature: Part of Eaton Bussmann Tron KAC family. Business Impact: Consistent performance across the family, enabling scalable protection across multi-channel power systems. Application: Rectifier banks, motor drives, and power distribution units.
Get a Quick Quote for a Eaton KAC-3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KAC-3?
Enquire Now
FAQs
Install the KAC-3 using blade end x blade end connections or mount it using the stud mounting option. Verify the fuse holder or panel cutout matches the 0.5 in depth and 0.5 in width footprint, and ensure secure electrical contact. Because this fuse is non-indicating, confirm status via your system's monitoring or diagnostic interface and consult the datasheet for torque specs and clearance requirements.
The KAC-3 fuse provides a 3 A amperage rating with a 200 kAIC interrupt rating. This combination enables fast fault clearing in power electronics circuits, reducing arc energy and protecting downstream components in rectifiers, drives, and power supplies. Always verify operating conditions align with the datasheet specifications for voltage and environment.
KAC-3 is well suited for rectifier modules, industrial drives, and power-supply protection in control panels. Its compact 0.5 x 0.5 inch footprint with blade end connections and stud mounting supports tight panel layouts, while its 3 A rating and 200 kAIC interrupt rating provide reliable protection for small to mid-size power electronics in manufacturing environments.
Yes. The KAC-3 fuse is UL Recognized and CE Marked, ensuring compliance with safety and regulatory requirements for global industrial equipment. This status supports expedited qualification for equipment across North America and Europe, reducing time-to-market for OEM assemblies and ensuring consistent protection across the Tron KAC family.
Because the KAC-3 is Non Indicating, supervision relies on your system’s fault-logging or indicator signals. Plan for spare fuses and standard stock based on your maintenance window. The blade end x blade end connections and stud mounting simplify replacement, while the compact form factor minimizes downtime during field swaps and service intervals.
