Eaton KAC-6 High Speed Fuse - UL Recognized, CE Marked
Part Number: KAC-6
Quick Summary
KAC-6 is a high-speed fuse designed for electrical protection in control panels and power distribution systems. Engineers often face nuisance trips and tight enclosure space, making a compact, fast-acting solution essential. This fuse carries UL Recognized and CE Marked certifications, ensuring regulatory compliance and safe interchange in global installations. With blade-end x blade-end connectivity and optional stud mounting, it fits dense panel layouts while delivering precise 6 A protection at up to 600 V. The Eaton Bussmann Tron KAC line provides reliable, industry-approved protection that supports maintenance planning and reduces spare-part inventories for automation and machinery applications.
Product Information
Extended Description
KAC-6 Eaton: Eaton Bussmann series Tron KAC high speed fuse, 6A, 200 kAIC, Non Indicating, High speed fuse, Blade end X blade end, Stud
Product Name
Eaton Bussmann series Tron KAC high speed fuse
Catalog Number
KAC-6
UPC
051712470063
Product Length/Depth
0.5 in
Product Height
2.84 in
Product Width
0.5 in
Product Weight
0.4 lb
Warranty
Not Applicable
Compliances
CE Marked
Certifications
UL Recognized
Amperage Rating
6 A
Interrupt rating
200 kAIC
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Mounting method
Stud
Feature: 6 A current rating with 200 kAIC interrupt capability translates to fast, reliable fault interruption in high-current surges. Business impact: protects downstream components and minimizes downtime, improving line efficiency in conveyors, presses, and automation controllers. Application: ideal for 600 V industrial control circuits where space is at a premium and fast clearing is required. Feature: Non-indicating operation reduces head-end monitoring costs and simplifies installation in cluttered panels. Business impact: lowers maintenance overhead and eliminates false-positive indicators that can mislead technicians. Application: suitable for panel-mounted fuse blocks in harsh factory environments. Feature: Blade end x blade end connection with optional stud mounting offers installation flexibility. Business impact: enables quick retrofits and adaptable mounting to existing enclosures, conserving cabinet real estate. Application: supports retrofits in legacy systems and new builds alike. Feature: UL Recognized and CE Marked certifications provide regulatory confidence. Business impact: mitigates compliance risk and accelerates acceptance across global sites. Application: ensures safe integration in multi-country electrical installations. Feature: Compact dimensions (0.5 in x 0.5 in x 2.84 in) and 0.4 lb weight. Business impact: minimizes enclosure footprint and handling effort during maintenance. Application: ideal for space-constrained control panels and automated machinery.
Get a Quick Quote for a Eaton KAC-6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KAC-6?
Enquire Now
FAQs
KAC-6 supports blade-end x blade-end connections and offers an optional stud mounting method, enabling flexible installation in many control panels. When wiring, ensure secure blade contacts and proper torque on any mounting hardware. The compact 0.5 in width and 2.84 in height help fit tight enclosures while maintaining reliable electrical contact and heat dissipation.
KAC-6 is rated for 6 A and provides an interrupt rating of 200 kAIC, with a maximum voltage rating of up to 600 V. These ratings deliver fast fault interruption for protecting sensitive upstream components, reduce arcing risk, and support safe operation in high-current control circuits typically found in automation and machinery panels.
Yes. The KAC-6 is designed for 600 V systems, offering UL Recognized and CE Marked compliance to meet global industrial standards. Its high interrupt rating and compact form factor make it ideal for space-constrained control cabinets and high-demand machinery protection, including conveyors and automated line equipment.
KAC-6 carries UL Recognized certification and CE Marking. UL Recognized confirms electrical safety and reliability for Western markets, while CE Marking signals compliance with European health, safety, and environmental requirements. Together, they streamline cross-border procurement and installation in industrial facilities.
Non-indicating fuses like KAC-6 reduce maintenance complexity by eliminating visual status indicators that can fail or mislead. This simplifies inventory management and reduces nuisance maintenance checks. For reliability, pair the fuse with periodic functional testing and verify panel wiring integrity during routine PM schedules.
