Eaton KAC-8 Tron high speed fuse - UL Recognized
Part Number: KAC-8
Quick Summary
KAC-8 high speed fuse protects electrical systems in motor drives and rectifier applications. Choosing fuses that meet both fast-acting protection and high interrupt ratings is challenging in harsh industrial environments. UL Recognized and CE Marked certifications provide critical safety and compliance assurance for global installations. With a 600 V rating, 8 A current capacity, and a 200 kAIC interrupt rating, this fuse delivers reliable short-circuit clearance. Its compact 0.5 in by 0.5 in footprint and stud mounting simplify installation in control panels and enclosures. By selecting a non-indicating, blade-end configuration from Eaton Bussmann Tron, you reduce downtime while maintaining protection for downstream equipment.
Product Information
Extended Description
KAC-8 Eaton: Eaton Bussmann series Tron KAC high speed fuse, 600V, 8A, 200 kAIC, Non Indicating, High speed fuse, Blade end X blade end, Stud
Product Name
Eaton Bussmann series Tron KAC high speed fuse
Catalog Number
KAC-8
UPC
051712470087
EAN
5027590510578
Product Length/Depth
0.5 in
Product Height
2.84 in
Product Width
0.5 in
Product Weight
0.4 lb
Warranty
Not Applicable
Compliances
CE Marked
Certifications
UL Recognized
Amperage Rating
8 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Mounting method
Stud
Feature: 600 V, 8 A, and 200 kAIC interrupt rating provide fast fault clearance. Business Impact: Higher reliability for motor drives and rectifiers reduces downtime and extends component life. Application: Ideal for industrial control panels where rapid protection and compact form factor are required. Feature: Blade end x blade end with stud mounting supports flexible installation. Business Impact: Simplifies field replacement and reduces panel wiring complexity. Application: Suitable for dense control cabinets where space and mounting options are constrained. Feature: Compact size of 0.5 in x 0.5 in and weight of 0.4 lb enables denser layouts. Business Impact: Reduces panel depth, lowers shipping and inventory costs, and improves serviceability. Application: Great for retrofits and new builds in compact equipment. Feature: UL Recognized and CE Marked certifications provide safety and regulatory alignment. Business Impact: Facilitates multi-region procurement and accelerates commissioning. Application: Suitable for multinational facilities with cross-border sourcing. Feature: Non-indicating (no visual fault indicator) fuse indicator. Business Impact: Reduces maintenance checks in automated lines; use remote status indications where needed. Application: Effective in automated assemblies where status is monitored downstream.
Get a Quick Quote for a Eaton KAC-8
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KAC-8?
Enquire Now
FAQs
The KAC-8 uses blade end x blade end connections and supports stud mounting. This combination enables flexible in-panel installation, including vertical and horizontal layouts, while maintaining robust electrical contact. Its compact 0.5 inch square footprint helps in tight control cabinets, reducing wiring complexity and simplifying retrofits or new installations.
The KAC-8 is rated for 600 V with an 8 A current rating and a 200 kAIC interrupt rating. These specifications enable rapid fault clearing for high-energy circuits in motor drives and rectifier applications, while maintaining coordination with upstream protective devices and minimizing arc energy in fault conditions.
Yes. The KAC-8 carries UL Recognized certification and CE Mark compliance, indicating conformity with global safety requirements. This dual certification supports multinational procurement, accelerates regulatory approvals, and provides assurance for safe operation in diverse industrial environments.
KAC-8 is well suited for motor drives, rectifier power supplies, and other industrial control panels requiring fast overcurrent protection. Its high interrupt rating and compact footprint enable reliable protection in space-constrained enclosures, while blade end and stud mounting support flexible installation in retrofit and new-build projects.
The KAC-8 contributes to ROI by reducing unexpected downtime through rapid fault clearance, minimizing downstream equipment damage, and lowering maintenance frequency due to robust, reliable protection. Its compact size and straightforward mounting also reduce install labor and spare parts inventory, delivering cost savings over the equipment’s lifecycle.
