Eaton KSCC-808A-02-90HB12 KwikSplice Cable Channel - UL
Part Number: KSCC-808A-02-90HB12
Quick Summary
Eaton KSCC-808A-02-90HB12 KwikSplice cable channel covers provide fast, secure protection for 2" wide cable runs used in control panels and industrial electrical spaces. This accessory addresses common pain points like messy routing and extended install times by simplifying bends with a 90-degree angle and a 12-inch radius. UL Listed and NEMA Compliant, the parts meet safety and regulatory expectations, while aluminum construction keeps weight down. Designed for durability and ease of maintenance, the cover height is 0.5 in and length 17.26 in, enabling a low-profile fit in crowded panels. For scalable installations, it pairs with Eaton's KwikSplice channel system to support efficient upgrades and predictable budgeting.
Product Information
Extended Description
KSCC-808A-02-90HB12 Eaton: Eaton B-Line series KwikSplice cable channel covers, KwikSplice cable channel cover for 2" wide, 90-degree horizontal bend, 12" radius
Product Name
Eaton B-Line series KwikSplice cable channel covers
Catalog Number
KSCC-808A-02-90HB12
UPC
799038826712
Product Length/Depth
17.26 in
Product Height
0.5 in
Product Width
17.26 in
Product Weight
0.08 lb
Compliances
NEMA Compliant
Certifications
UL Listed
Material
Aluminum
Type
Cover 2" 90 degree Horizontal Bend 12
Angle
90°
Radius
12 in
Support span - min
10 ft
KwikSplice cable channel Brochure
KwikSplice cable channel Instruction manual
Eaton Specification Sheet - KSCC-808A-02-90HB12
Eaton Specification Sheet - KSCC-808A-02-90HB12
Feature: KwikSplice cable channel covers are specified for a 2" wide system with a 90° horizontal bend and a 12" radius. Business impact: this geometry delivers a precise, fast-fit installation that minimizes field adjustments and reduces risk of cable crowding. Application: ideal for line-side wiring in control panels and equipment rooms where space around elbows is at a premium.Feature: Aluminum construction provides a lightweight yet durable housing. Business impact: lowers handling strain during installation and enhances corrosion resistance in harsh environments. Application: suitable for indoor industrial enclosures and exposed electrical rooms. Feature: Certifications and compliance, including UL Listed and NEMA Compliant. Business impact: supports code compliance and audit readiness, reducing project risk and rework. Application: mandatory for facilities in regulated sectors and energy installations. Feature: Low-profile dimensions—0.5 in height and 17.26 in length—help preserve enclosure geometry. Business impact: enables more usable space for cables, connectors, and terminal blocks, while maintaining clean aesthetics. Application: retrofits and new builds where space is at a premium. Feature: Compatibility with the KwikSplice cable channel system. Business impact: simplifies procurement and spares training time for maintenance teams, enabling faster upgrades. Application: scalable solutions across facilities that rely on Eaton's KwikSplice ecosystem. Feature: Lightweight weight of 0.08 lb per cover contributes to total system efficiency. Business impact: reduces shipment costs and on-site fatigue during installation and replacements. Application: large installations with many spans or frequent access points.
Get a Quick Quote for a Eaton KSCC-808A-02-90HB12
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KSCC-808A-02-90HB12?
Enquire Now
FAQs
These covers are designed for use with Eaton's KwikSplice system to enclose cables along a 2 inch wide channel, including a 90° bend with a 12 inch radius. They install as a direct add-on to the channel segment, enabling a clean, protected run without requiring special tools.
The cover is aluminum, with a 0.5 inch height, 17.26 inch length, for a 2 inch wide channel, and accommodates a 90° bend with a 12 inch radius. It is UL Listed and NEMA Compliant, offering lightweight protection suitable for industrial environments.
Yes. Its low-profile 0.5 inch height and 17.26 inch length help maximize enclosure space, while maintaining required protection and easy access for maintenance in control panels and electrical rooms.
The cover is UL Listed and NEMA Compliant, signaling compliance with safety and regulatory standards essential for audits, code adherence, and safe operation in industrial facilities.
The cover reduces installation time, simplifies cable routing around bends, lowers maintenance downtime, and minimizes risk of cable displacement, contributing to lower total cost of ownership in scalable Eaton KwikSplice installations.
