Eaton KSCC-808A-04-90VO12 KwikSplice Covers - NEMA
Part Number: KSCC-808A-04-90VO12
Quick Summary
KSCC-808A-04-90VO12 is a KwikSplice cable channel cover used to protect 4-inch-wide electrical runs in industrial and commercial installations. Installers often face bulky, slow-to-install covers that drive labor costs; this lightweight aluminum design speeds assembly and reduces field handling. It is NEMA compliant and NEMA certified, aligning with industry standards for reliability in demanding environments. With a 90-degree vertical outside corner and a 12-inch radius, it fits tight spaces while keeping cables organized across long runs. Together, these features translate to faster deployments and lower lifecycle costs, while staying compatible with Eaton's KwikSplice channel ecosystem.
Product Information
Extended Description
KSCC-808A-04-90VO12 Eaton: Eaton B-Line series KwikSplice cable channel covers, KwikSplice cable channel cover for 4" wide, 90-degree vertical outside, 12" radius
Product Name
Eaton B-Line series KwikSplice cable channel covers
Catalog Number
KSCC-808A-04-90VO12
UPC
799038826552
Product Length/Depth
4.52 in
Product Height
17.03 in
Product Width
17.03 in
Product Weight
0.15 lb
Compliances
NEMA Compliant
Certifications
NEMA
Material
Aluminum
Type
Cover 4" 90 Degree Vertical Out 12
Angle
90°
Radius
12 in
Support span - min
10 ft
KwikSplice cable channel Brochure
KwikSplice cable channel Instruction manual
KwikSplice cable channel tray specifications
KwikSplice cable channel tray specifications
Aluminum construction delivers corrosion resistance and lighter weight, reducing handling fatigue during field installs and extending service life in harsh environments. This translates to lower maintenance costs and fewer field replacements in busy facilities, making it ideal for retrofit projects or new installations where downtime must be minimized. The 4-inch wide footprint, 90-degree vertical outside corner, and 12-inch radius simplify routing around equipment and along walls, reducing the need for intermediate fittings and fasteners while accelerating installation timelines on crowded work sites. The NEMA-compliant design provides regulatory confidence for standard electrical installations, helping you meet project and contractor requirements without overengineering. Dimensional clarity—4.52 in depth, 17.03 in height and width—and a light 0.15 lb weight per cover enable easy handling and precise planning during layout and knock-out reviews. KwikSplice compatibility ensures seamless integration with existing channel systems, reducing rework and supporting scalable cable management. A minimum support span of 10 ft helps engineers specify spans confidently in long runs, minimizing sag and potential cable exposure. In practice, this means faster project turnover, predictable maintenance intervals, and a safer, neater cable path for critical infrastructure such as data centers, manufacturing floors, and service corridors.
Get a Quick Quote for a Eaton KSCC-808A-04-90VO12
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KSCC-808A-04-90VO12?
Enquire Now
FAQs
KSCC-808A-04-90VO12 is designed for the 4-inch KwikSplice cable channel system with a 90-degree vertical outside corner and a 12-inch radius. It installs as a cover for the channel, aligning with the catalog’s 4.52 in depth and 17.03 in width/height dimensions, and snaps into place within the KwikSplice ecosystem, enabling quick field deployment and straightforward maintenance.
The cover is made from aluminum, offering corrosion resistance and lightweight handling. It is NEMA compliant and NEMA certified, ensuring it meets established electrical enclosure standards for reliable performance in industrial environments.
Yes. The 4-inch wide, 90-degree outside corner design with a 12-inch radius is well-suited for data centers, equipment rooms, and service corridors where organized, protected cable routing is essential and space constraints favor tight corner coverage.
The product carries NEMA compliance and certification, reflecting adherence to recognized electrical enclosure standards. For project managers, this reduces regulatory risk and simplifies supplier qualification when specifying cable management for commercial and industrial installations.
Its aluminum construction, lightweight profile, and KwikSplice compatibility enable faster installation with minimal handling, reducing labor costs. The 10 ft minimum support span supports longer runs with fewer joints, improving reliability and lowering lifecycle maintenance costs in busy facilities.
