Eaton KSCC-808A-04-HX12 KwikSplice Cable Channel Covers - UL Listed
Part Number: KSCC-808A-04-HX12
Quick Summary
Eaton KSCC-808A-04-HX12 KwikSplice cable channel covers deliver durable wire management for 4\" wide cross runs in industrial enclosures. Tight spaces, mixed cabling, and evolving codes can slow installs and increase the risk of damage; this cover solves those challenges with a lightweight aluminum design and a quick snap-on installation. UL Listed and NEMA compliant, with a 12\" radius, the assembly supports safe, code‑compliant pathways even in demanding environments. Designed for fast deployment and long‑term reliability, it helps engineering teams improve wiring discipline, reduce downtime, and meet maintenance windows using standard KwikSplice channel systems.
Product Information
Extended Description
KSCC-808A-04-HX12 Eaton: Eaton B-Line series KwikSplice cable channel covers, KwikSplice cable channel cover for 4" wide horizontal cross, 12" radius
Product Name
Eaton B-Line series KwikSplice cable channel covers
Catalog Number
KSCC-808A-04-HX12
UPC
799038826835
Product Length/Depth
34 in
Product Height
0.5 in
Product Width
34 in
Product Weight
1.26 lb
Compliances
NEMA Compliant
Certifications
UL Listed
Material
Aluminum
Type
Cover 4" Horizontal Cross 12
Radius
12 in
Support span - min
10 ft
KwikSplice cable channel Brochure
KwikSplice cable channel Instruction manual
KwikSplice cable channel tray specifications
KwikSplice cable channel tray specifications
Feature: Aluminum construction provides a lightweight yet robust profile with corrosion resistance ideal for indoor and controlled environments. Business Impact: Improves handleability on long runs and lowers installation labor costs while maintaining mechanical integrity. Application: Compatible with 4\" wide cross KwikSplice cable channels in Eaton B-Line systems. Feature: 12 in radius minimizes bends in the channel, reducing need for retrofit fittings. Business Impact: Speeds routing and minimizes stock of extra parts. Application: Best for continuous 4\" cross runs in panels and enclosures. Feature: 34 in length with 0.5 in height and 34 in width yields a low-profile, continuous cover. Business Impact: Fewer seams, fewer gaps, better cable containment. Application: Ideal for long, straight runs in equipment rooms. Feature: UL Listed and NEMA Compliant ensures regulatory acceptance. Business Impact: Streamlines audits and safety compliance. Application: Suitable for wiring closets, control cabinets, and industrial enclosures. Feature: Minimum 10 ft support span enables flexible mounting layouts. Business Impact: Reduces hardware count and simplifies rack/channel planning. Application: Appropriate for warehouses, data centers, and manufacturing floors. Feature: Snap-on cover design for KwikSplice channel compatibility. Business Impact: Cuts installation time and minimizes field handling. Application: Works with Eaton B-Line KwikSplice cable channel systems.
Get a Quick Quote for a Eaton KSCC-808A-04-HX12
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KSCC-808A-04-HX12?
Enquire Now
FAQs
KSCC-808A-04-HX12 is designed for 4" wide horizontal cross KwikSplice cable channels in industrial enclosures, control panels, and equipment rooms. Its 34" length and 12" radius support clean, code-compliant wire routing across long runs, reducing the need for additional fittings. The aluminum construction delivers a robust, lightweight solution suitable for demanding environments while maintaining ease of installation.
Installation is designed to be fast and straightforward: align the cover with the KwikSplice channel, then snap it into place. The 34" length provides a continuous run with minimal joints. The lightweight aluminum construction helps installers handle and position the cover quickly, reducing labor time and disruption to ongoing operations.
Yes. KSCC-808A-04-HX12 is specifically designed for the Eaton B-Line KwikSplice cable channel family. Its 4" cross-coverage and 12" radius match the channel geometry, enabling a secure, integrated fit that simplifies field upgrades and expands existing installations without channel modifications.
Key dimensions include a length/depth of 34 inches, width of 34 inches, and a height of 0.5 inches. The cover weighs approximately 1.26 pounds, providing a sturdy yet manageable profile for use in racks, cabinets, and wall-mounted enclosures.
The product supports a minimum span of 10 feet between supports. This guidance helps optimize mounting layouts, reduce hardware counts, and ensure a structurally sound run for longer cable channels in data centers, manufacturing floors, and large control cabinets.
