Eaton KTK-12 Fuse - 100 kAIC at 600 V; Small footprint
Part Number: KTK-12
Quick Summary
The Eaton KTK-12 fuse is a fast-acting protection device designed for control circuits, lighting, and meter circuits in compact control panels. Engineers often struggle with space constraints and unreliable protection in crowded enclosures, leading to unnecessary downtime. This fuse delivers a small footprint, high interrupt capability, and robust endcaps to improve reliability and panel density. Boasting CE marking and RoHS compliance, it aligns with EU safety and environmental standards, supporting compliant installations across regional programs. For buyers seeking efficient protection with minimal footprint, the KTK-12 offers strong business value without compromising performance or regulatory adherence.
Product Information
Extended Description
KTK-12 Eaton: Eaton Bussmann series KTK fuse, Control circuits, Lighting circuit protection, Meter circuits, 12 A, Non-indicating, Ferrule end x ferrule end, 100 kAIC at 600 V, Nickel-plated bronze endcap, Melamine tube, 600 V
Product Name
Eaton Bussmann series KTK fuse
Catalog Number
KTK-12
UPC
051712420082
EAN
5027590445825
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.19 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
12 A
Interrupt rating
100 kAIC at 600 Vac
Voltage rating
600 V
Material
Melamine tube Nickel-plated bronze endcap
Packaging type
Standard
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Small footprint
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - KTK-12
KTK-12~LIMITRON FAST ACTING FUSE
Datasheet - FNQ-30
Feature → Business Impact → Application: 12 A amperage rating provides precise protection for low- to mid-range control circuits, reducing nuisance trips and enabling predictable maintenance windows in PLC and relay-based panels. This translates to improved uptime and lower service costs in manufacturing lines where fast response to faults is critical. Feature → High interrupt rating of 100 kAIC at 600 V ensures rapid fault clearing in high-energy environments, protecting downstream equipment and reducing arc-flash exposure for technicians during maintenance. Feature → Ferrule end x ferrule end connections enable quick, secure termination with standard crimp fittings, speeding up installation and minimizing mis-wiring risk in field assemblies across machine centers. Feature → Small footprint delivers greater panel density, allowing more components per enclosure and simplifying cabinet layout for control systems in packaging, material handling, and process automation. Feature → Melamine tube with nickel-plated bronze endcaps offers mechanical robustness and耐 corrosion resistance for harsher environments, extending service life in off-gel or damp locations. Feature → Non-indicating fuse and fast-acting LIMITRON behavior balance visibility and protection, reducing replacement cycles while ensuring fast fault interruption for sensitive electronics and motors. In practice, these characteristics support compliance with industry best practices and facilitate quick upgrades to existing Bussmann-series installations.
Get a Quick Quote for a Eaton KTK-12
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KTK-12?
Enquire Now
FAQs
The KTK-12 features ferrule end x ferrule end connections, allowing secure termination with standard crimp ferrules. Use compatible fuse holders or clips designed for ferrule-ended fuses, follow the panel manufacturer's torque guidelines, and ensure the circuit is de-energized before installation to prevent arcing and ensure safe maintenance.
KTK-12 is a 12 A fast-acting fuse rated for 600 V with an interrupt rating of 100 kAIC at 600 Vac. This combination protects control circuits, lighting, and metering circuits against short circuits while minimizing nuisance trips in normal inrush scenarios, enabling reliable equipment protection.
Yes. With a 12 A rating and 600 V capability, KTK-12 supports lighting and meter circuits commonly found in industrial control panels. Its fast-acting character helps prevent damage from short circuits in these applications while maintaining compatibility with Bussmann-series accessories and standard panel hardware.
KTK-12 carries CE marking and RoHS compliance, ensuring regulatory alignment for EU installations and reduced hazardous substances in assemblies. This supports compliance-driven procurement and helps streamline cross-border deployments in manufacturing environments.
The small footprint and high reliability reduce panel space usage and the risk of unexpected outages. Fast interruption characteristics minimize damage to downstream equipment, lowering repair costs and downtime. Compatibility with standard Bussmann-series components simplifies spare parts planning and maintenance.
