Eaton KTK-2-1/2 Fuse - 100 kAIC at 600 V, RoHS CE
Part Number: KTK-2-1/2
Quick Summary
KTK-2-1/2 fuse by Eaton delivers reliable control-circuit protection in compact industrial panels. This fast-acting device addresses space constraints typical of modern control cabinets, where a small footprint can mean the difference between a functional layout and a crowded enclosure. The fuse is RoHS compliant and CE marked, reinforcing regulatory readiness for global deployments, with a 600 V rating and 100 kAIC interrupt capability for robust mains protection. It supports control circuits, lighting circuits, and meter circuits, delivering consistent performance over time. By combining simple ferrule-end connections with durable nickel-plated endcaps, it reduces wiring complexity while maintaining installation efficiency and long-term reliability in industrial environments.
Product Information
Extended Description
KTK-2-1/2 Eaton: Eaton Bussmann series KTK fuse, Control circuits, Lighting circuit protection, Meter circuits, 2.5 A, Non-indicating, Ferrule end x ferrule end, 100 kAIC at 600 V, Nickel-plated bronze endcap, Melamine tube, 600 V
Product Name
Eaton Bussmann series KTK fuse
Catalog Number
KTK-2-1/2
UPC
051712420228
EAN
5027590445856
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.19 lb
Warranty
Not Applicable
Compliances
RoHS Compliant CE Marked
Amperage Rating
2.5 A
Interrupt rating
100 kAIC at 600 Vac
Voltage rating
600 V
Material
Melamine tube Nickel-plated bronze endcap
Packaging type
Standard
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Small footprint
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - KTK-2-1/2
KTK-2-1/2~KTK-2-1-2~LIMITRON FAST ACTING FUSE
The KTK-2-1/2 fuse offers a small footprint that frees precious panel space, enabling more compact control cabinets and easier wiring runs. The 2.5 A amperage rating paired with a 600 V maximum rating provides precise protection for low-current control circuits without nuisance trips, improving overall equipment uptime. A 100 kAIC interrupt capability ensures fast and reliable fault clearance in mains-connected applications, enhancing safety and reducing downstream damage. Ferrule-end x ferrule-end terminations simplify installation and replacement within standard fuse blocks, while the melamine tube and nickel-plated bronze endcaps deliver robust thermal and mechanical performance in harsh industrial settings. Non-indicating design keeps costs down, though external status indicators can be added where fault visibility is required. The fuse’s RoHS and CE compliance supports global deployment and regulatory alignment, and its compact form-factor supports flexible cabinet layouts and efficient maintenance planning. In short, it combines regulatory readiness, space efficiency, and dependable protection for industrial automation and electrical protection and circuit control needs.
Get a Quick Quote for a Eaton KTK-2-1/2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KTK-2-1/2?
Enquire Now
FAQs
KTK-2-1/2 is designed for control circuits, lighting circuits, and meter circuits inside industrial panels where space is at a premium. It uses ferrule-end terminations and a compact body, delivering reliable fast-acting protection without crowding the enclosure. Ideal for compact automation cabinets, it supports efficient wiring, straightforward replacement, and predictable performance in harsh industrial environments.
Key ratings include a 2.5 A amperage rating, 600 V voltage rating, and 100 kAIC interrupt rating, enabling safe interruption of fault currents in control and power circuits. The fuse is non-indicating, which reduces panel wear and costs, while the melamine tube and nickel-plated bronze endcaps provide robust mechanical and thermal performance for long service life.
Yes. The KTK-2-1/2 is RoHS compliant and CE marked, aligning with European regulatory requirements and restricted substances standards. This simplifies global deployment for machine builders and integrators, ensuring your control panels meet current environmental and safety directives, and supports compatibility with international product standards.
The fuse is compact, with a body length and width of 0.41 in and a height of 1.5 in, weighing about 0.19 lb. This small footprint frees space in crowded control panels and enables easier routing of control wiring, while ferrule-end construction simplifies installation in standard fuse blocks and reduces mounting complexity.
Non-indicating fuses rely on external status indicators or system fault monitoring. For maintenance, plan periodic checks of external indicators or integrate with a panel-level status circuit. The fast-acting LIMITRON design provides predictable trip behavior, and replacement is straightforward due to ferrule-terminal design and a standard form factor that fits common Bussmann-style fuse blocks.
