Eaton KTK-7-1/2 Fuse - 100 kAIC at 600 V
Part Number: KTK-7-1/2
Quick Summary
Eaton KTK-7-1/2 fuse protects control circuits and lighting in industrial panels. It addresses the challenge of selecting a fuse that meets 600 V system demands while delivering reliable interrupt performance across diverse loads. CE Marked and RoHS compliant certifications help ensure global regulatory readiness. With a 7.5 A rating and 100 kAIC interrupt capability, it delivers robust protection without nuisance trips. The ferrule-end connections simplify installation and minimize wiring issues in panel builds, while a compact 0.41 in by 0.41 in cross-section supports dense layouts. This fuse aligns with modern automation strategies, delivering predictable protection, reduced downtime, and streamlined procurement for maintenance-heavy facilities.
Product Information
Extended Description
KTK-7-1/2 Eaton: Eaton Bussmann series KTK fuse, Control circuits, Lighting circuit protection, Meter circuits, 7.5 A, Non-indicating, Ferrule end x ferrule end, 100 kAIC at 600 V, Melamine tube, Nickel-plated bronze endcap, 600 V
Product Name
Eaton Bussmann series KTK fuse
Catalog Number
KTK-7-1/2
UPC
051712179072
EAN
5027590446044
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.19 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
7.5 A
Interrupt rating
100 kAIC at 600 Vac
Voltage rating
600 V
Material
Melamine tube Nickel-plated bronze endcap
Packaging type
Standard
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - KTK-7-1/2
Feature: 7.5 A amperage rating combined with a 100 kAIC interrupt rating provides rapid protection for fault currents in control circuits and lighting feeders. Business impact: This minimizes damage to drives, relays, and contactors, reducing downtime from fault events. Application: Ideal for rugged industrial panels where reliable protection is essential to maintain production uptime. Feature: Ferrule end x ferrule end connections enable secure, vibration-resistant terminations. Business impact: Faster, more repeatable installations lower commissioning time and wiring errors. Application: Suitable for dense layouts in machine cabinets and distributed control panels, where space is at a premium. Feature: 600 V voltage rating supports both control circuits and lighting circuits in industrial environments. Business impact: Provides margin for transients and ensures compliance with common power rails. Application: Useful in meter circuits, lighting protection, and general control protection across automation projects. Feature: Non-indicating design reduces upfront costs while allowing status to be observed via external systems. Business impact: Simplifies maintenance planning and reduces nuisance indicator failures. Application: Aligns with centralized protection schemes and OEM configurations that rely on panel-level monitoring. Feature: Melamine tube construction with nickel-plated bronze endcaps delivers durability under thermal cycling and frequent switching. Business impact: Longer service life lowers spare parts spend and replacement intervals. Application: Performs reliably in harsh industrial environments such as manufacturing floors and process lines. Feature: Dimension and packaging details offer a compact footprint: 0.41 in length/depth, 0.41 in width, and 1.5 in height; standard packaging supports compact panel design. Business impact: Enables denser protection layouts and easier scoping of fuse inventories. Application: Ideal for modern control panels and lighting distribution modules. Compliance and ecosystem: CE Marked and RoHS Compliant certifications provide regulatory assurance for global deployments. Business impact: Reduces compliance risk for multinational projects and simplifies vendor qualification. Application: Fits Eaton Bussmann series protection ecosystem for seamless integration with other fuses and protection devices. Compatibility and procurement: Ferrule end terminations are compatible with standard ferrule crimps used in control panels. Business impact: Streamlines stocking and substitutions, improving maintenance efficiency. Application: Widely compatible across Eaton and Bussmann fuse families for consistent protection strategy. Performance mindset: The KTK-7-1/2 fuse supports efficient maintenance planning, predictable coordination with upstream protection, and improved MTBF in automation lines.
Get a Quick Quote for a Eaton KTK-7-1/2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KTK-7-1/2?
Enquire Now
FAQs
KTK-7-1/2 uses ferrule end x ferrule end terminals, enabling secure, vibration-resistant terminations. This design simplifies panel wiring, reduces commissioning time, and lowers the likelihood of loose connections in harsh environments. Ensure ferrule crimps match standard sizes used in your panel fabrications for best results.
The fuse is rated for 7.5 A typical operating current, with a 100 kAIC interrupt rating at 600 V. Its voltage rating is 600 V, making it suitable for control circuits, lighting feeds, and meter circuits in industrial applications.
Yes. With a 600 V rating and a 100 kAIC interrupt capability, the KTK-7-1/2 provides robust protection for lighting circuits and other auxiliary loads within industrial panels, helping to prevent fault propagation and equipment damage.
The KTK-7-1/2 carries CE Marking and RoHS compliance, enabling global deployment and regulatory alignment across many regions. These certifications support procurement standards and reduce compliance risk in multinational projects.
The high interrupt rating and reliable protection minimize downtime from faults, reduce spare parts usage, and simplify maintenance planning. While exact ROI varies by system, the fuse's durability and compliance can yield lower total cost of ownership over time.
