Eaton KTK-9 Fuse - 9 A, 100 kAIC @ 600 V, CE RoHS
Part Number: KTK-9
Quick Summary
KTK-9 fuse from Eaton provides reliable overcurrent protection for control, lighting, and metering circuits. Engineers often confront tight panel spaces and the need for high interrupt ratings to prevent costly downtime. It is RoHS compliant and CE marked, with a 100 kAIC interrupt rating at 600 V for demanding industrial environments. Designed for panel builders and OEMs, it combines a compact ferrule-end design with reliable Bussmann performance. In practice, this enables faster stocking, easier installation, and consistent protection across critical electrical loops. The 9 A current rating suits control circuits, lighting feeders, and meter boards in industrial automation, helping maintain reliability and uptime. With RoHS and CE compliance, procurement teams meet regulatory expectations while standard Bussmann-series protection aligns with global component inventories.
Product Information
Extended Description
KTK-9 Eaton: Eaton Bussmann series KTK fuse, Control circuits, Lighting circuit protection, Meter circuits, 9 A, Non-indicating, Ferrule end x ferrule end, 100 kAIC at 600 V, Melamine tube, Nickel-plated bronze endcap, 600 V
Product Name
Eaton Bussmann series KTK fuse
Catalog Number
KTK-9
UPC
051712420211
EAN
5027590446068
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.19 lb
Warranty
Not Applicable
Compliances
RoHS Compliant CE Marked
Amperage Rating
9 A
Interrupt rating
100 kAIC at 600 Vac
Voltage rating
600 V
Material
Melamine tube Nickel-plated bronze endcap
Packaging type
Standard
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - KTK-9
KTK-9~LIMITRON FAST ACTING FUSE
Datasheet - FNQ-30
Feature: 9 A amperage rating paired with a 100 kAIC interrupt rating at 600 V delivers dependable protection for powered control circuits. Business Impact: high interrupt capacity supports fast fault clearance, reduces thermal stress on downstream devices, and minimizes downtime in critical lines. Application: ideal for panel-mounted control circuits, machine logic, lighting feeders, and meter circuit protection within industrial automation environments. Feature: Ferrule-end terminations standardize installation, enabling quick, tool-free wiring in common fuse holders and terminal blocks. Business Impact: reduces labor time and field error rates during panel assembly. Application: interconnections in control panels, lighting panels, and meter enclosures across OEM builds. Feature: Melamine tube with nickel-plated bronze endcaps provides robust mechanical and electrical performance. Business Impact: extended service life and reduced replacement costs under harsh operating conditions. Application: industrial panels exposed to dust, vibration, or humidity. Feature: RoHS compliant and CE marked ensures global regulatory alignment. Business Impact: simplifies cross-border procurement and reduces compliance risk. Application: European and global manufacturing networks. Feature: Compact dimensions and lightweight design (0.41 in W x 0.41 in D x 1.5 in H; 0.19 lb). Business Impact: saves panel space and lowers shipping/stocking costs. Application: tight panel spaces and high-volume OEM installations. Feature: Standard packaging and ferrule-end connections streamline stocking and replacement in existing Bussmann-based fleets. Business Impact: improved inventory planning and faster maintenance cycles. Application: mass deployment across industrial automation and electrical protection tasks. Feature: Non-indicating design reduces cost and simplifies visual inspection in clean-room or price-sensitive environments. Business Impact: lowers component cost without compromising protection in non-indicating variants. Application: budget-conscious control panels and lighting circuits where indication is unnecessary.
Get a Quick Quote for a Eaton KTK-9
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KTK-9?
Enquire Now
FAQs
The KTK-9 uses ferrule-end terminations, which are compatible with common fuse holders and terminal blocks found in industrial control panels. This design enables quick, tool-free installation and reduces wiring errors during panel assembly. For retrofit projects, ensure the existing holders match ferrule-end fuses to maintain secure connections and consistent protection.
The KTK-9 provides a 9 A current rating with a 100 kAIC interrupt rating at 600 V. This combination supports fast fault clearance in control circuits, lighting feeders, and meter circuits, while safely handling typical startup surges in industrial applications. These specs help protect downstream devices and minimize downtime due to short circuits.
Yes. The KTK-9 is designed for control circuits, lighting circuit protection, and meter circuits in industrial automation. Its compact size, high interrupt rating, and durable construction make it a practical choice for panel builders and OEMs seeking reliable protection in space-constrained panels.
The KTK-9 is RoHS compliant and CE marked, ensuring regulatory alignment for EU and global manufacturing. This simplifies cross-border procurement, supports environmental and safety standards, and reduces compliance risk in multinational production environments.
The KTK-9's non-indicating design reduces part costs and inventory complexity while maintaining robust protection. Its high interrupt rating minimizes downtime by quickly clearing faults, and the ferrule-end design speeds field replacement. Overall, this translates to lower maintenance labor costs, fewer spare part SKUs, and improved panel uptime across fleets.
