Eaton KTK-R-1/10 Fuse - 0.1 A, 200 kAIC UL Listed

Part Number: KTK-R-1/10
KTK-R-1/10
Manufacturer
Eaton
Part number
KTK-R-1/10
Category

Quick Summary

The Eaton KTK-R-1/10 fuse is a fast-acting, current-limiting protection device designed for industrial control panels and machinery. Engineers often contend with nuisance trips and selecting fuses that balance protection with uptime in demanding environments. UL Listed, CSA Certified, CE Marked and RoHS compliant, this fuse supports global installations and regulatory compliance. Its ferrule-end connections and Class CC compatibility simplify panel wiring and inventory management, while the dual-element design enhances reliability in noisy electrical environments. For manufacturers and integrators, it offers predictable protection, easy sourcing, and reduced maintenance costs across diverse applications such as lighting, motor control, and capacitor banks.

Product Information

Extended Description

KTK-R-1/10 Eaton: Eaton Bussmann Series Class CC fuse, KTK-R, fast-acting, dual-element current limiting fuse, 0.1 A, rejection style fuse, interrupting rating of 200kA at 600Vac
Product Name
Eaton Bussmann series KTK-R fuse
Catalog Number
KTK-R-1/10
UPC
051712420518
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.18 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting fast-acting fuse
Special features
Rejection style
Application
Industrial controls panels and machinery, street lighting, general lighting, capacitors and distribution
Amperage Rating
0.1 A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end Ferrule
Response time
See time current curve
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 V
Low Voltage Branch Circuit Fuse Chapter Low Voltage Branch Circuit Fuse Chapter Low Voltage Branch Circuit Fuse Chapter Bussmann series Fuseology Eaton Specification Sheet - KTK-R-1/10 KTK-R Spec Sheet KTK-R Spec Sheet
Feature: Current-limiting fast-acting design provides rapid fault interruption. Business Impact: Minimizes energy let-through, reduces arc flash risk, and protects downstream components, improving equipment uptime and personnel safety. Application: Ideal for industrial control panels and machinery where fast clearing of faults matters. Feature: 200 kAIC interrupt rating improves protection for high-energy circuits. Business Impact: Supports robust circuit protection in demanding power environments, enabling longer equipment life and less unplanned downtime. Application: Street lighting, general lighting, and distribution panels. Feature: 0.1 A amperage rating enables precise protection for small-load circuits and sensing networks. Business Impact: Prevents nuisance trips while preserving functional loads, lowering maintenance costs. Application: Control circuits, relays, and instrumentation buses. Feature: Rejection style ferrule-end connections simplify safe, unambiguous installation. Business Impact: Reduces mis-wiring and installation errors, accelerating commissioning. Application: Panel assemblies and field replacements. Feature: Certifications and compliance (UL Listed, CSA Certified, CE Marked, RoHS). Business Impact: Facilitates global procurement and regulatory conformity, reducing vendor risk. Application: Multinational deployments and cross-border projects. Feature: Packaging type and quantity (Standard packaging, 10 units per package) support efficient stocking and just-in-time maintenance. Business Impact: Lower inventory carrying costs and faster replacement cycles. Application: Discrete renewable and industrial systems with frequent fuse replacements.

Get a Quick Quote for a Eaton KTK-R-1/10

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton KTK-R-1/10? Enquire Now

FAQs

The KTK-R-1/10 fuse offers a 200 kAIC interrupt rating, which indicates its capability to reliably interrupt short-circuit fault currents up to 200 kiloamps. This is critical in protecting feeders, motors, and downstream devices in high-energy industrial systems while minimizing arc energy and equipment damage.
Yes. The KTK-R-1/10 is a Class CC, current-limiting fast-acting fuse with ferrule-end x ferrule-end connections, designed for straightforward installation in Class CC fuse holders and panel assemblies without special adapters.
This fuse is well suited for industrial controls panels and machinery, street lighting, general lighting, capacitors, and distribution networks where precise protection, fast fault clearing, and reliable operation are essential.
The KTK-R-1/10 carries UL Listed, CSA Certified, CE Marked, and RoHS compliance. These certifications support global procurement, regulatory adherence, and reduced supplier risk across multinational deployments.
Plan for ferrule-end terminations, ensure the circuit operates within 600 V ratings, and consult the time-current curve to select the appropriate response time for your fault conditions. The 0.1 A rating is ideal for protecting small-load circuits without nuisance tripping.
