Eaton KTK-R-3/4 Fuse - Class CC, 0.75A, 200 kAIC
Part Number: KTK-R-3/4
Quick Summary
The Eaton KTK-R-3/4 fuse provides fast-acting current-limiting protection for industrial control panels and machinery. This design helps prevent nuisance trips and equipment damage in space-constrained enclosures, where inrush and capacitive loads can threaten uptime. It carries UL Listed, CSA Certified, RoHS Compliant, and CE Marked certifications to support compliant installations across global facilities. By combining precise protection with straightforward integration, this fuse reduces maintenance burdens and supports reliable distribution in harsh industrial environments, while aligning with your broader safety and compliance programs.
Product Information
Extended Description
KTK-R-3/4 Eaton: Eaton Bussmann Series Class CC fuse, KTK-R, fast-acting, dual-element current limiting fuse, 0.75 A, rejection style fuse, interrupting rating of 200kA at 600Vac
Product Name
Eaton Bussmann series KTK-R fuse
Catalog Number
KTK-R-3/4
UPC
051712420570
EAN
5027590445658
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.019 lb
Warranty
Not Applicable
Compliances
RoHS Compliant CE Marked
Certifications
UL Listed CSA Certified
Type
Current-limiting fast-acting fuse
Special features
Rejection style
Application
Industrial controls panels and machinery, street lighting, general lighting, capacitors and distribution
Amperage Rating
0.75 A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end Ferrule
Response time
See time current curve
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 V
Bussmann Full Line Catalog
Bussmann Full Line Catalog
Bussmann Full Line Catalog
Bussmann series Fuseology
Eaton Specification Sheet - KTK-R-3/4
KTK-R Spec Sheet
KTK-R Spec Sheet
Feature → Dual-element current-limiting design provides rapid fault clearance while tolerating brief inrush surges → Reduces thermal damage and downtime, improving overall equipment reliability in control panels and machinery. Application: Industrial controls panels and machinery benefit from clean, predictable protection and minimized false trips. Feature → 0.75 A Amperage Rating with Class CC construction → Enables targeted protection for small to medium circuits without nuisance trip escalation, lowering spare parts needs and maintenance costs. Application: Lighting ballast, capacitive loads, small DC/AC drives. Feature → 200 kAIC interrupt rating at 600 V → Delivers high fault current interruption capability, safeguarding feeders and distribution assets during short circuits. Application: Distribution and street lighting networks in industrial facilities. Feature → Rejection style ferrule-end connections → Prevents incorrect fuse installation and ensures secure, vibration-resistant terminations. Application: Panelboards and control cabinets where reliable wiring is essential. Feature → RoHS Compliant, CE Marked, UL Listed, CSA Certified → Delivers regulatory confidence and environmental compliance across regional code requirements. Application: Global manufacturing sites with strict supplier qualifications. Feature → Time-current characteristics with “See time current curve” specification and dual-element design → Improves coordination with downstream protection while reducing arc energy during fault events. Application: General lighting, capacitors, distribution networks, and industrial controls.
Get a Quick Quote for a Eaton KTK-R-3/4
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KTK-R-3/4?
Enquire Now
FAQs
Plan for ferrule-end terminations with a 1.5 inch length, ensure clearance for a 600 V rated device, and verify that the mounting supports a Class CC fuse module. The KTK-R-3/4 is designed for secure, vibration-resistant connections and straightforward panel integration in industrial cabinets.
The dual-element current-limiting design provides rapid fault clearing while tolerating short-lived inrush, reducing nuisance trips during startup or capacitor discharge. This translates to smoother operation of loads like lighting and motors and improves overall panel reliability.
Yes. With a 0.75 A rating, 600 V capability, and 200 kAIC interrupt rating, it provides robust protection for lighting feeders and distribution circuits, while the rejection-style ferrule ends simplify installation and reduce mis-wiring risks in outdoor and semi-outdoor environments.
The KTK-R-3/4 carries UL Listed and CSA Certified marks, along with RoHS compliance and CE marking. These certifications support compliance with safety, environmental, and regional requirements across North America and Europe.
Track fault events with the time-current curve, replace immediately after a trip to prevent cascading faults, and maintain an appropriate spare fuse inventory. The KTK-R-3/4's reliability and predictable response help reduce downtime and inventory costs in distributed control systems.
