Eaton KTK-R-6/10 Fuse - 200 kAIC Class CC, UL Listed
Part Number: KTK-R-6/10
Quick Summary
Eaton Bussmann KTK-R fuse protects industrial controls panels and machinery with fast-acting, current-limiting protection. This device helps engineers prevent costly downtime by rapidly clearing faults without excessive current interruption. The fuse’s dual-element design minimizes nuisance trips in fluctuating load conditions and supports reliable operation across mission-critical equipment. It carries UL Listed and CSA Certified marks and CE RoHS compliance, ensuring compliance with global safety and environmental standards. For procurement teams, the compatibility with Bussmann series families simplifies stocking and maintenance. In short, KTK-R-6/10 delivers predictable protection, easy replacement in standard fuse holders, and robust performance in demanding industrial environments.
Product Information
Extended Description
KTK-R-6/10 Eaton: Eaton Bussmann Series Class CC fuse, KTK-R, fast-acting, dual-element current limiting fuse, 0.6 A, rejection style fuse, interrupting rating of 200kA @ 600Vac
Product Name
Eaton Bussmann series KTK-R fuse
Catalog Number
KTK-R-6/10
UPC
051712420501
EAN
5027590416788
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.017 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting fast-acting fuse
Special features
Rejection style
Application
Industrial controls panels and machinery, street lighting, general lighting, capacitors and distribution
Amperage Rating
0.6 A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end Ferrule
Response time
See time current curve
Material
Nickel-plated brass endcap Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 V
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
Bussmann series Fuseology
Eaton Specification Sheet - KTK-R-6/10
KTK-R Spec Sheet
KTK-R Spec Sheet
Feature: Dual-element current-limiting fast-acting fuse; Business Impact: fast fault clearance with limited energy, reducing arc flash risk and downstream damage; Application: protects industrial controls and motor drives in panels. Feature: Amperage rating of 0.6 A and voltage rating of 600 V; Business Impact: precise protection for small- to mid-range circuits, enabling safe operation and minimizing nuisance blows; Application: control circuits, lighting panels, distribution blocks. Feature: Interrupt rating of 200 kAIC; Business Impact: high fault-current tolerance protects equipment in severe electrical faults, lowering replacement costs; Application: high-energy panels and feeders. Feature: Rejection style with ferrule ends; Business Impact: prevents incorrect fuse installation and ensures reliable seating in standard holders; Application: plug-in class CC fuse blocks and enclosure assemblies. Feature: Compliance and packaging; Business Impact: UL Listed, CSA Certified, CE RoHS, with standard packaging for easy procurement and inventory control; Application: industrial controls projects and field retrofits. Feature: Time-current characteristics; Business Impact: predictable clearing times support coordinated protection schemes; Application: utility, street lighting, and capacitor banks.
Get a Quick Quote for a Eaton KTK-R-6/10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton KTK-R-6/10?
Enquire Now
FAQs
KTK-R-6/10 uses ferrule-end connections and is designed for Class CC fuse holders. Install in standard panel blocks compatible with Bussmann ferrule-end fuses, ensuring proper seating and alignment. Verify the enclosure rating and ensure the circuit voltage is within 600 V and the current rating is appropriate for the protected load. Consult the time-current curve from the datasheet to coordinate selectivity with upstream protections.
The 200 kAIC interrupt rating indicates the fuse can safely interrupt very high fault currents without excessive arcing. This protects downstream devices, wiring, and transformers from catastrophic damage and reduces the risk of collateral failure during faults. It is particularly important in systems with high short-circuit currents or large distribution panels.
Yes. The 0.6 A, 600 V rating and current-limiting, fast-acting characteristics make it suitable for street lighting gear, general lighting, and capacitor/distribution networks. Its high interrupt rating and dual-element design help coordinate protection with feeders and capacitors, while the rejection-style ferrule ends simplify correct replacement in standard housings.
KTK-R-6/10 is UL Listed and CSA Certified, with CE Marking and RoHS compliance. These certifications support regulatory compliance for North American and global deployments and help streamline safety documentation,_component traceability, and environmental requirements in procurement specifications.
The current-limiting, fast-acting design reduces fault energy, minimizing downtime and downstream damage. Its rejection-style ferrule end and standardized Class CC form factor simplify stocking, replacement, and maintenance. Over time, this can lower maintenance labor costs, extend equipment life, and improve overall system uptime in industrial installations.
