Eaton KTK-R-9 Fuse - Class CC, 200 kAIC, 600V

Part Number: KTK-R-9
KTK-R-9
Manufacturer
Eaton
Part number
KTK-R-9
Category

Quick Summary

KTK-R-9 fuse provides fast-acting, current-limiting protection for industrial controls panels and power distribution. In the field, engineers often contend with nuisance tripping and inconsistent protection that drives unplanned downtime. This Bussmann Series device carries UL Listed and CSA Certified marks, plus CE RoHS compliance, ensuring regulatory alignment and safe installation. With dual-element protection, a Class CC form factor, and a 200 kAIC interrupt rating at 600 V, it supports compact panel layouts without compromising protection. Designed for industrial controls panels, street lighting, and distribution networks, the KTK-R-9 also delivers predictable time-current behavior, making procurement and maintenance simpler for engineering teams.

Product Information

Extended Description

KTK-R-9 Eaton: Eaton Bussmann Series Class CC fuse, KTK-R, fast-acting, dual-element current limiting fuse, 9 Amp rejection style fuse, interrupting rating of 200kA at 600Vac
Product Name
Eaton Bussmann series KTK-R fuse
Catalog Number
KTK-R-9
UPC
051712420723
EAN
5027590445733
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting fast-acting fuse
Special features
Rejection style
Application
Industrial controls panels and machinery, street lighting, general lighting, capacitors and distribution
Amperage Rating
9 A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end Ferrule
Response time
See time current curve
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 V
Bussmann Full Line Catalog Bussmann Full Line Catalog Bussmann Full Line Catalog Bussmann Full Line Catalog Bussmann series Fuseology Eaton Specification Sheet - KTK-R-9 KTK-R Spec Sheet KTK-R Spec Sheet
Feature: Current-limiting fast-acting design with dual elements; Business Impact: Faster fault clearance minimizes arc energy and equipment stress, reducing downtime and extending component life; Application: Industrial control panels, motor starters, and power distribution. Feature: Class CC, 9 A rating; Business Impact: Standardized sizing and reliable protection for low-to-mid current circuits, improving panel consistency and reducing nuisance trips; Application: Control panels and lighting drivers. Feature: 600 V rating with 200 kAIC interrupt capacity; Business Impact: Higher fault tolerance and safety margin in high-energy systems, enabling safer installations in industrial environments; Application: Capacitors, distribution blocks, and street lighting networks. Feature: Ferrule end connections; Business Impact: Easy field wiring and secure mounting, lowering installation time and error rates; Application: Quick-panel builds and retrofit projects. Feature: Compliance and certifications (UL Listed, CSA Certified, CE RoHS); Business Impact: Regulatory confidence and smoother qualification for global deployments; Application: Any certified industrial application requiring recognized safety marks. Feature: Rejection style; Business Impact: Prevents inadvertent mix-ups during replacement, improving reliability and maintenance planning; Application: High-volume procurement and standardized spares stock.

Get a Quick Quote for a Eaton KTK-R-9

Chat with us on WhatsApp - fast responses guaranteed

Need to speak with someone? We'll call you back within 2 hours during business hours

Interested in Eaton KTK-R-9? Enquire Now

FAQs

KTK-R-9 uses ferrule end connections and a Class CC form factor, making it compatible with standard industrial control panels, lighting panels, and machinery panels that use Bussmann Series fuse geometries. It fits common DIN-rail or chassis-based layouts when paired with appropriate ferrule-terminals, enabling straightforward retrofits and new builds.
The KTK-R-9 is a 9 A current-limiting, fast-acting fuse rated for 600 V and provides an interrupt rating of 200 kAIC. This combination supports protection for medium-current control circuits, capacitors, and distribution networks while maintaining fast fault clearance in high-energy environments.
Yes. The KTK-R-9 is UL Listed and CSA Certified, with CE Marking and RoHS compliance. This combination ensures regulatory acceptance in many regions, simplifies qualification processes, and supports environmentally responsible manufacturing and end-use.
Ideal for industrial controls panels, street lighting, general lighting, capacitors, and distribution circuits. Its dual-element design and high interrupt rating make it suitable for protecting power supplies, motor control centers, and other critical infrastructure while helping keep downtime to a minimum.
The KTK-R-9 offers predictable protection curves, reduced nuisance trips, and secure ferrule-term connections that speed up installation and maintenance. With UL/CSA/CE marks, it minimizes qualification risk, supports standard spare stocking (packaging of 10), and lowers total cost of ownership through longer mean time between failures and simpler procurement.
