Eaton L1020CWBK Watertight Locking Connector - IP67
Part Number: L1020CWBK
Quick Summary
The L1020CWBK watertight locking connector from Eaton provides reliable back-wired power connections for industrial equipment in harsh, wet locations. This design minimizes corrosion risk and water ingress, addressing a common failure point in outdoor controls. It carries IP67 protection and RoHS compliance, supported by cULus Listed certification, ensuring safety and regulatory alignment for North American installations. Built for back wiring with #18-10 AWG conductors, it supports 125/250V, 20A operation in a three-pole arrangement. The combination of a nylon body, nickel-plated brass contacts, and Santoprene elastomeric seal delivers durable, vibration-resistant performance, reducing maintenance and unplanned downtime while enabling faster, safer field terminations for industrial automation projects.
Product Information
Extended Description
L1020CWBK Eaton: Eaton Arrow Hart watertight locking connector, #18-10 AWG, 20A, Industrial, 125/250V, Back wiring, Black, Steel, Watertight, L10-20, Three-pole, Three-wire, non-grounding, Santoprene thermoplastic elastomeric, 0.43 to 1.15 in, IP67
Product Name
Eaton Arrow Hart watertight locking connector
Catalog Number
L1020CWBK
UPC
032664708794
Product Length/Depth
6.38 in
Product Height
3.82 in
Product Width
4.4 in
Product Weight
1.025 lb
Compliances
RoHS Compliant
Certifications
cULus Listed NOM
Amperage Rating
20A
Degree of protection
IP67
NEMA configuration
L10-20
Number Of Poles
Three-pole
Number of wires
Non-grounding 3
Torque rating
14-16 lbf-inch
Voltage rating
125/250 V
Environmental resistance
NEMA 4X IP67 NEMA 6P NEMA 4 NEMA 6
Allowable wire size
#18-10 AWG
Wiring method
Back
Color
Black
Contact material
Nickel plated brass
Application
Industrial
Cord diameter
0.43-1.15 in
Design type
Watertight locking connector
Device grade
Extra heavy-duty industrial specification grade
Face/body material
Nylon
Material
Santoprene thermoplastic elastomeric
Special features
Watertight
Type
Locking connector
The L1020CWBK delivers IP67 watertight protection in a compact locking connector design, reducing moisture ingress and ensuring reliable operation on exposed equipment. This feature translates to fewer shutdowns and maintenance cycles in washdown areas and outdoor enclosures, enabling more up-time for conveyors and automation lines. Back-wiring with #18-10 AWG wires and a torque range of 14-16 lbf-in provides secure terminations with predictable seating, accelerating panel assembly in control cabinets and modular machines. The nylon face and body, coupled with nickel-plated brass contacts and a Santoprene elastomeric seal, offer robust corrosion resistance and long service life in harsh environments, minimizing replacement costs. Rated for 125/250V and 20A, with L10-20 NEMA configuration, it ensures compatibility with standard plant power systems, reducing adapters and simplifying wiring in industrial automation projects. The RoHS compliance and cULus listing support regulatory adherence for global deployments, while IP67 and NEMA 4X/6 ratings give confidence for outdoor, damp, and washdown settings. Overall dimensions of 6.38 in length, 3.82 in height, and 4.4 in width, plus a weight of 1.025 lb and a cord dia range of 0.43-1.15 in, help with planning, space, and serviceability in compact enclosures.
Get a Quick Quote for a Eaton L1020CWBK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton L1020CWBK?
Enquire Now
FAQs
The L1020CWBK uses back-wiring for #18-10 AWG conductors with a recommended torque of 14–16 lbf-in to ensure a secure connection. The nickel-plated brass contacts provide reliable termination, while the Santoprene seal and nylon body protect against moisture. Follow manufacturer guidelines for stripping length and seating to avoid loosening under vibration.
Rated for 20A at 125/250V with a three-pole, non-grounding arrangement, the connector follows the L10-20 NEMA configuration. This combination supports reliable power distribution in industrial equipment and aligns with standard North American single- or three-phase systems.
Yes. The connector is IP67 rated and listed with NEMA 4X/6 protections, making it ideal for outdoor, wet, and washdown environments where moisture, dust, and temporary immersion pose a risk to electrical joints.
The L1020CWBK is RoHS compliant and cULus Listed NOM, providing regulatory alignment for clean-room, consumer, and industrial installations. These certifications help ensure safety, environmental compliance, and smoother approvals in many global markets.
Using a watertight locking connector reduces maintenance and downtime due to moisture ingress and loose terminations. Its rugged materials, reliable back-wiring, and standard voltage/wire-size compatibility streamline panel builds and service, translating to faster deployment, fewer field faults, and improved uptime in industrial automation.
