Eaton L1420RW Watertight Locking Receptacle - IP66
Part Number: L1420RW
Quick Summary
Eaton L1420RW watertight locking receptacle provides rugged, reliable power for outdoor industrial equipment. Moisture, dust, and harsh surroundings can cause corrosion and intermittent connections, driving downtime and maintenance costs. This receptacle carries NOM cULus Listed, UL Listed, CSA certified, and meets Federal Specifications W-C375, with IP66/NEMA 4X protection for dependable operation. Designed for #14-8 AWG back wiring and L14-20 three-pole configurations, it simplifies installation while delivering a robust, watertight connection. With thermoplastic construction and nickel-plated bronze contacts, it combines durability, safety, and regulatory clarity for industrial buyers. This combination supports faster maintenance and lower total cost of ownership over the life of the system.
Product Information
Extended Description
L1420RW Eaton: Eaton Arrow Hart watertight locking receptacle, #14-8 AWG, 20A, Industrial, 125/250V, Back wiring, Yellow, Single, Watertight, L14-20, Three-pole, Four-wire, Thermoplastic
Product Name
Eaton Arrow Hart watertight locking receptacle
Catalog Number
L1420RW
UPC
040893687759
Product Length/Depth
6.75 in
Product Height
4 in
Product Width
4.25 in
Product Weight
1.025 lb
Compliances
Federal Specifications Classification W-C375
Certifications
NOM cULus Listed UL Listed CSA certified
Amperage Rating
20A
NEMA configuration
L14-20
Number Of Poles
Three-pole
Number of wires
4 Grounding
Receptacle type
Locking
Torque rating
For #10-14 AWG: 14-16 lbf-inch. For #8 AWG: 20 lbf-inch
Voltage rating
125/250 V
Environmental resistance
NEMA 4 NEMA 3 NEMA 4X IP66 NEMA 12 NEMA 3R
Allowable wire size
#14-8 AWG
Wiring method
Back
Color
Yellow
Contact material
Nickel plated bronze
Application
Industrial
Design type
Single receptacle
Device grade
Extra heavy-duty industrial specification grade
Face/body material
Glass filled nylon
Material
Thermoplastic
Special features
Watertight
Type
Locking receptacle
Watertight protection translates to fewer field failures in wet locations, improving uptime and safety for outdoor equipment. This locking receptacle secures connections under vibration and harsh conditions, reducing accidental disconnections and rework in high-motion industrial environments. Back wiring for #14-8 AWG conductors enables faster, error-resistant installations, lowering labor costs and field fatigue. Glass-filled nylon face and thermoplastic body deliver impact resistance and long-term durability in demanding plants, while nickel-plated bronze contacts ensure consistent conductivity and corrosion resistance in challenging environments. Compliance with IP66/NEMA 4X and Federal Specifications W-C375 helps satisfy procurement requirements for regulated projects and ensures market acceptance. Torque values—14-16 lbf-in for #10-14 AWG and 20 lbf-in for #8 AWG—support reliable performance and predictable field servicing. This receptacle is compatible with standard L14-20 configurations and aligns with industry best practices for industrial power distribution in outdoor facilities.
