Eaton L1620PWBK watertight locking plug - IP67
Part Number: L1620PWBK
Quick Summary
Eaton L1620PWBK watertight locking plug provides rugged, reliable three-phase connections for industrial equipment. In harsh plants, moisture intrusion and environmental contaminants can trigger downtime and unsafe terminations; this plug’s IP67 sealing and back-wiring capability help prevent leaks and simplify field terminations. It carries cULus Listed certification and RoHS compliance, with IP67 environmental protection and compatibility with NEMA L16-20 configurations. By combining robust materials with a compact footprint, it supports faster installations, reduced maintenance costs, and improved panel reliability. For engineers and procurement teams, this plug aligns with essential industrial standards while delivering long service life in demanding environments and enabling compliant wiring with #18-10 AWG.
Product Information
Extended Description
L1620PWBK Eaton: Eaton Arrow Hart watertight locking plug, #18-10 AWG, 20A, Industrial, 480V, Back wiring, Black, Steel, Watertight, L16-20, Three-pole, Four-wire, Santoprene, 0.36 to 0.84 in, IP67
Product Name
Eaton Arrow Hart watertight locking plug
Catalog Number
L1620PWBK
UPC
032664709043
Product Length/Depth
6.75 in
Product Height
4 in
Product Width
4.25 in
Product Weight
1.025 lb
Compliances
RoHS Compliant
Certifications
cULus Listed
Amperage Rating
20A
Degree of protection
IP67
NEMA configuration
L16-20
Number Of Poles
Three-pole
Number of wires
Grounding 4
Torque rating
14-16 lbf-inch
Voltage rating
3Ø 480 V
Environmental resistance
NEMA 6 IP67 NEMA 4X NEMA 6P NEMA 4
Allowable wire size
#18-10 AWG
Wiring method
Back
Color
Black
Contact material
Nickel plated brass
Application
Industrial
Cord diameter
0.36-0.84 in
Design type
Watertight locking plug
Device grade
Extra heavy-duty industrial specification grade
Face/body material
Nylon
Material
Santoprene
Special features
Watertight
Type
Locking plug
Watertight sealing and IP67/NEMA 6 protection guard against water and dust ingress, reducing downtime and extending service life in wet or wash-down zones. This translates to fewer maintenance calls and more uptime on critical equipment in automation cabinets and outdoor installations. The 20A, 3-pole, 4-wire configuration (L16-20) supports standard 3Ø loads at 480V, enabling seamless integration with existing motor starters and drive systems. Back wiring for #18-10 AWG simplifies field terminations, speeding up installation and improving termination reliability while reducing commissioning time. Nickel-plated brass contacts paired with Santoprene seals ensure corrosion resistance and a tight, durable connection in harsh environments, decreasing replacement costs over the life of the installation. The nylon face/body gives a lightweight yet rugged housing, contributing to easy handling and consistent engagement in dense panel layouts. With a torque rating of 14–16 lbf-in, installations stay secure without over-tightening, supporting operator safety and equipment protection.
