Eaton L2020CWBK Locking Connector - IP67 Industrial Grade
Part Number: L2020CWBK
Quick Summary
Eaton L2020CWBK locking connector is a watertight power connection solution for industrial equipment. In harsh environments, field wiring can be error-prone and slow, leading to downtime and reliability concerns. This device carries RoHS compliance and cULus listing while delivering IP67 protection and a 347/600V, 20A rating in a four-pole, non-grounding configuration. It is designed for back wiring, supporting #18-10 AWG cables with a secure four-wire connection. By combining rugged construction with easy installation, this connector helps procurement reduce risk and total cost of ownership while meeting industrial standards and performance expectations.
Product Information
Extended Description
L2020CWBK Eaton: Eaton Arrow Hart watertight locking connector, #18-10 AWG, 20A, Industrial, 347/600V, Back wiring, Black, Steel, Watertight, L20-20, Four-pole, Four-wire, Santoprene thermoplastic elastomeric, 0.36 to 0.84 in, IP67
Product Name
Eaton Arrow Hart watertight locking connector
Catalog Number
L2020CWBK
UPC
032664709241
Product Length/Depth
6.38 in
Product Height
3.82 in
Product Width
4.4 in
Product Weight
1.025 lb
Compliances
RoHS Compliant
Certifications
cULus Listed
Amperage Rating
20A
Degree of protection
IP67
NEMA configuration
L20-20
Number Of Poles
Four-pole
Number of wires
4 Non-grounding
Torque rating
14-16 lbf-inch
Voltage rating
3ØY 347/600 V
Environmental resistance
NEMA 4X NEMA 6P NEMA 4 NEMA 6 IP67
Allowable wire size
#18-10 AWG
Wiring method
Back
Color
Black
Contact material
Nickel plated brass
Application
Industrial
Cord diameter
0.36-0.84 in
Design type
Watertight locking connector
Device grade
Extra heavy-duty industrial specification grade
Face/body material
Nylon
Material
Santoprene thermoplastic elastomeric
Special features
Watertight
Type
Locking connector
Feature: IP67 watertight protection and rugged NEMA compatibility. Business Impact: Protects sensitive electrical connections from dust, water, and immersion, reducing failure rates in outdoor or wash-down environments. Application: Outdoor equipment, wash-down areas, and corrosive industrial settings. Feature: Four-pole, four-wire non-grounding configuration rated for 20A. Business Impact: Supports three-phase power delivery and high-current loads with reliable isolation, improving panel efficiency. Application: Industrial power distribution, machine controllers, and motor drives. Feature: Back wiring method with a 0.36-0.84 in cord diameter range. Business Impact: Faster field terminations and simpler maintenance, lowering labor costs and downtime. Application: Field installations in rugged production lines. Feature: Nylon face/body and Santoprene thermoplastic elastomeric material. Business Impact: High impact resistance and chemical compatibility, extending service life in harsh environments. Application: Heavy-duty industrial devices and equipment housings. Feature: Nickel-plated brass contacts and nickel plating for corrosion resistance. Business Impact: Maintains low contact resistance and long-term reliability in challenging industrial atmospheres. Application: Power connectors in harsh plants and outdoor sites. Feature: 347/600V voltage rating and 14–16 lbf-in torque rating. Business Impact: Ensures secure electrical connections with dependable performance across peak loads. Application: High-voltage industrial circuits and equipment assemblies. Feature: RoHS compliant and cULus Listed. Business Impact: Simplifies compliance, reduces risk in procurement, and supports regulatory and safety programs. Application: Facility-wide electrical assemblies and compliant installations.
Get a Quick Quote for a Eaton L2020CWBK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton L2020CWBK?
Enquire Now
FAQs
The L2020CWBK supports back wiring with #18-10 AWG conductors, enabling straightforward terminations. Its four-pole, non-grounding design and 0.36-0.84 inch cord diameter range provide flexibility for common industrial cables, while the stays-on locking mechanism ensures secure, vibration-resistant connections in panels and equipment enclosures.
This connector is rated for 20A, with a voltage rating of 347/600V and an IP67 degree of protection. The four-pole, four-wire configuration (non-grounding) supports robust three-phase power delivery while maintaining ingress protection against dust and water in challenging environments.
Yes. The IP67 rating, NEMA compatibility (L20-20), and rugged Nylon/Santoprene construction make it well-suited for outdoor applications and wash-down zones. It tolerates moisture, dust, and mechanical stress, reducing downtime and maintenance costs in harsh industrial environments.
The L2020CWBK is RoHS compliant and cULus listed, supporting regulatory compliance and safety requirements in many regions. These certifications streamline sourcing decisions, simplify approvals in quality programs, and reduce risk in supplier audits while ensuring reliable performance.
Maintenance is minimized by its durable nylon body, Santoprene seal, and corrosion-resistant nickel-plated brass contacts, which resist wear in dusty or damp environments. The locking mechanism reduces loosening during vibration, lowering rework and downtime, and extending service life for critical industrial connections.
