Eaton L2020PWBK Watertight locking plug - IP67
Part Number: L2020PWBK
Quick Summary
Eaton L2020PWBK watertight locking plug provides robust, back-wired power connections for industrial equipment and control panels. In harsh environments, moisture, dust, and vibration can compromise terminations and drive costly downtime. This connector is RoHS compliant and cULus listed, with IP67 sealing and a rugged NEMA L20-20 configuration designed for demanding service. Designed for #18-10 AWG conductors and 347/600 V three-phase systems, it streamlines installation while delivering consistent torque and a reliable seal. Together with its nickel-plated brass contacts and Santoprene sealing, the L2020PWBK reduces maintenance costs, extends service life, and supports safer, compliant industrial operation.
Product Information
Extended Description
L2020PWBK Eaton: Eaton Arrow Hart watertight locking plug, #18-10 AWG, 20A, Industrial, 347/600V, Back wiring, Black, Steel, Watertight, L20-20, Four-pole, Four-wire, Santoprene, 0.36 to 0.84 in, IP67
Product Name
Eaton Arrow Hart watertight locking plug
Catalog Number
L2020PWBK
UPC
032664709258
Product Length/Depth
6.38 in
Product Height
3.82 in
Product Width
4.4 in
Product Weight
1.025 lb
Compliances
RoHS Compliant
Certifications
cULus Listed
Amperage Rating
20A
Degree of protection
IP67
NEMA configuration
L20-20
Number Of Poles
Four-pole
Number of wires
Non-grounding 4
Torque rating
14-16 lbf-inch
Voltage rating
3ØY 347/600 V
Environmental resistance
NEMA 6P NEMA 4X IP67 NEMA 4 NEMA 6
Allowable wire size
#18-10 AWG
Wiring method
Back
Color
Black
Contact material
Nickel plated brass
Application
Industrial
Cord diameter
0.36-0.84 in
Design type
Watertight locking plug
Device grade
Extra heavy-duty industrial specification grade
Face/body material
Nylon
Material
Santoprene
Special features
Watertight
Type
Locking plug
Watertight locking plug design delivers IP67 protection, protecting terminations from moisture and dust in wet or dusty environments; this reduces unplanned downtime and improves equipment reliability in manufacturing and processing plants. Back wiring support for #18-10 AWG simplifies field terminations, minimizes wiring errors, and shortens installation time, delivering measurable labor savings and more consistent connections in panel assemblies. The four-pole, four-wire configuration operates at 347/600 V with a 20 A rating and a NEMA L20-20 layout, enabling reliable three-phase power delivery to motors and control gear in harsh conditions. Nickel-plated brass contacts offer corrosion resistance and stable electrical performance, while Santoprene seals and a Nylon body provide lasting mechanical integrity and chemical resilience in demanding environments. The cord-diameter range of 0.36–0.84 in supports diverse cord sets, ensuring a tight seal and repeatable engagement even in vibratory applications. Compliance with RoHS and cULus reduces regulatory risk and streamlines procurement, while the locking mechanism minimizes accidental disconnections in installations with motion or vibration.
Get a Quick Quote for a Eaton L2020PWBK
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton L2020PWBK?
Enquire Now
FAQs
Yes, L2020PWBK supports back-wiring with #18-10 AWG conductors. It uses a torque range of 14-16 lbf-in to ensure a secure, repeatable connection without over-tightening, which helps prevent conductor damage and maintains voltage integrity in vibration-prone equipment.
The L2020PWBK is rated for 20A at 347/600 V and configured as NEMA L20-20. It provides four poles with four wires (non-grounding) and is designed for three-phase industrial power distribution in demanding environments.
This locking plug excels in industrial panels, motors, and control cabinets exposed to moisture, dust, or vibration. Its IP67 sealing, back-wiring capability, and robust construction make it suitable for manufacturing, material handling, and outdoor equipment installations.
The L2020PWBK is RoHS compliant and cULus listed, confirming conformance to environmental and safety standards. Its IP67 rating also supports compliance with ingress protection requirements in harsh environments.
The combination of nickel-plated brass contacts, Santoprene sealing, and a Nylon body delivers durable electrical performance with resistance to corrosion and seals that maintain integrity over time. This reduces maintenance cycles, lowers replacement costs, and improves overall uptime for critical industrial equipment.
