Eaton LG3500A13S02 MCCB - UL Listed

Part Number: LG3500A13S02
LG3500A13S02
Manufacturer
Eaton
Part number
LG3500A13S02
Category

Quick Summary

Eaton LG3500A13S02 MCCB is a high-capacity molded case circuit breaker designed for critical electrical protection in industrial power distribution. In generator and heavy-load environments, outages and equipment damage can spike during startup transients, and this device helps prevent such issues through precise tripping. It carries UL Listed, CSA Certified, and IEC Rated certifications, ensuring compliance across North American and international markets. The Series C design supports engine-generator applications, 600 Vac protection, and a three-pole configuration with rear auxiliary/shunt options, delivering reliable protection while streamlining installation and serviceability for your power systems.

Product Information

Extended Description

LG3500A13S02 Eaton: Eaton Series C complete molded case circuit breaker, L-frame, Fixed thermal and magnetic trips, 600-2500A, Three-pole, 500A, 600 Vac, Line/load, Engine generator, 2A-2B rear w/ right pigtail, 12-24 Vac/dc rear w/ left pigtail, Reverse feed
Product Name
Eaton Series C complete molded case circuit breaker
Catalog Number
LG3500A13S02
UPC
782114871744
Product Length/Depth
5.48 in
Product Height
5.48 in
Product Width
5.48 in
Product Weight
16 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed CSA Std. C22.2 No. 5 IEC 947-2 CSA Certified UL 489 IEC Rated
Amperage Rating
500 A
Voltage rating
600 Vac
Trip Type
T186
Circuit breaker frame type
Complete breaker
Auxiliary switch
2A-2B rear with right pigtail
Series
Series C
Shunt trip
12-24 Vac/dc rear with left pigtail shunt
Terminals
Line and load
Frame
L
Class
Engine generator
Generator rating
181 kVA/144 kW at 240 Vac, 361 kVA/289 kW at 480 Vac, 451 kVA/361 kW at 600 Vac
Number of poles
Three-pole
Trip rating
600-2500 A
Functions
Reverse
