Eaton LGE3300FAG Molded Case Circuit Breaker - 65 kAIC @240V

Trip Type and Coordination: The LGE3300FAG employs fixed thermal with an adjustable magnetic trip (T185), enabling precise coordination across three phases to minimize nuisance trips while safeguarding upstream equipment. Business impact includes improved uptime and reduced maintenance costs in high-demand panels, particularly in motor control centers used in manufacturing lines. Application: ideal for large-load feeders and control panels where predictable trip characteristics are essential. Amperage Rating and Frame: At 300 A, LG frame supports significant motor and feeder protection within a compact footprint, enabling plug-and-play integration in existing LG-series distributions. Impact: lowers total panel size, simplifies retrofits, and improves space efficiency in crowded electrical rooms. Application: upgrade projects in retrofits or new builds requiring robust main protection. Interrupt Rating and Voltage Range: With 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 18 kAIC at 600 Vac, devices deliver strong fault current handling across standard industrial voltages. Impact: enhances system safety margins and compliance with regional codes during commissioning. Application: distribution panels in 3-phase environments with mixed voltage requirements. Terminals and Mounting: Line and load terminals support straightforward wiring with metric mounting hardware, enabling fast field installation and reliable terminations. Impact: reduces installation time and potential connection faults, improving commissioning efficiency. Application: new installations and panel upgrades where wiring is constrained by space. Certifications and Compliance: UL Listed, CSA Certified, and CE Marked, plus HACR-rated notes ensure broad regulatory acceptance and safe operation in commercial and industrial settings. Impact: simplifies procurement and audit readiness, reducing validation time for compliance. Application: panel builders and end-users seeking multi-region certification coverage. Warranty and Support: Eaton’s policy 25-000 provides a one-year from installation or eighteen months from shipment warranty, backed by Eaton service centers. Impact: lowers lifecycle risk and supports quick problem resolution in field service. Application: procurement and long-term maintenance planning for critical plant assets.
