Eaton LP-CC-1-1/8 Fuse - Class CC UL Listed
Part Number: LP-CC-1-1/8
Quick Summary
Eaton LP-CC-1-1/8 fuse is a current-limiting time-delay device designed for specialized industrial control circuits. Industrial panels frequently contend with nuisance trips during motor starts and transient overloads; a fast, predictable protection solution is essential. This fuse carries UL Listed, CSA Certified, and CE RoHS compliance, with CE marking for European markets and RoHS compliance for restricted substances. The product leverages dual-element construction for reliable interruption while minimizing arc energy, supporting safer control panels. Designed for Bussmann LP-CC series compatibility, it streamlines spares and field service. With a compact ferrule-to-ferrule profile and robust 600 Vac / 300 Vdc ratings, it delivers dependable protection in demanding environments and supports maintenance-friendly installation.
Product Information
Extended Description
LP-CC-1-1/8 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 0.5 A, rejection style fuse, interrupting rating of 200kA at 600Vac and 20kA at 300Vdc
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-1-1/8
UPC
051712180443
EAN
5027590172967
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
1.125A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC at 600 Vac 20 kAIC at 300 Vdc
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 300 Vdc
Time-delay, dual-element design – reduces nuisance trips while preserving fault interruption; ideal for motor starts and control panels in harsh industrial environments. This translates to higher uptime and safer startup sequences in automated lines and machine controls. 1.125 A amperage rating provides precise protection for low-current control circuits, reducing false trips in sensors, PLC inputs, and signaling loops while extending component life. Application emphasis includes automation panels, relay banks, and sensor networks where stable protection is critical. Interrupt rating of 200 kAIC at 600 Vac and 20 kAIC at 300 Vdc ensures robust fault-current handling in large equipment and feeders, lowering risk of downstream damage. Rejection-style ferrule end connections prevent incorrect installation and support reliable coordination in Class CC branch circuits. Certifications and compliance—UL Listed, CSA Certified, CE RoHS—confirm suitability for global deployments. The compact 0.41 in by 0.41 in footprint and 1.5 in height, with a 0.15 lb weight and standard packaging of ten, simplify replacement and inventory management in maintenance programs.
Get a Quick Quote for a Eaton LP-CC-1-1/8
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-1-1/8?
Enquire Now
FAQs
The LP-CC-1-1/8 fuse is designed to be compatible with Bussmann LP-CC class CC fuse holders, featuring ferrule-end terminations that fit standard ferrule mounts. This ensures straightforward replacement in existing LP-CC based panels and MCCs, reducing downtime during maintenance and facilitating standardized spares across multiple pieces of equipment.
With an amperage rating of 1.125 A and an interrupt rating of 200 kAIC at 600 Vac (and 20 kAIC at 300 Vdc), the LP-CC-1-1/8 provides precise protection for low-current control circuits while guaranteeing safe interruption of large fault currents. This combination supports reliable protection for motor starters and control panels under high fault-current conditions without unnecessary nuisance trips.
Best suited for specialized circuits and industrial control applications, including motor starters, relays, PLC I/O, and control panels in manufacturing environments. Its Class CC current-limiting, dual-element construction delivers dependable protection in complex automation systems where selective coordination and minimized arc energy are critical.
The LP-CC-1-1/8 fuse is UL Listed and CSA Certified, with CE RoHS compliance. These certifications support global deployment in regulated facilities and ensure restricted use of hazardous substances, aiding in conformity with regional electrical standards and supplier quality requirements.
Expect easier maintenance with standard ferrule-end connections and a compact footprint that fits common LP-CC holders. The dual-element time-delay design reduces nuisance trips, improving line uptime and machine availability. With standard packaging of ten units per pack and a robust interrupt rating, it supports lower spare parts inventory costs and faster field replacements, delivering measurable total cost of ownership improvements.
