Eaton LP-CC-1-4/10 Fuse - 200 kAIC at 600 Vac
Part Number: LP-CC-1-4/10
Quick Summary
The Eaton LP-CC-1-4/10 fuse provides time-delay current-limiting protection for industrial control circuits. Engineers often struggle with nuisance trips and downtime when protecting complex machines during startup. Certified CE Marked RoHS Compliant, UL Listed, and CSA Certified, this fuse aligns with global safety standards while supporting regulatory compliance. Its dual-element design and compact ferrule-end connections simplify installation in crowded control panels, delivering predictable response and long service life. Using this fuse helps protect specialized circuits and reduces maintenance costs by preventing premature fuse replacements. In practice, you gain higher reliability in applications demanding precise time-delay protection and robust interrupt ratings.
Product Information
Extended Description
LP-CC-1-4/10 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 1.4 A, rejection style fuse, interrupting rating of 200 kA at 600 Vac and 20 kA at 300 Vdc
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-1-4/10
UPC
051712180467
EAN
5027590221528
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
1.40A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC at 600 Vac 20 kAIC at 300 Vdc
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 300 Vdc
Feature: Time-delay current-limiting dual-element design. Business Impact: Smooth startup with effective short-circuit protection reduces nuisance trips and equipment wear. Application: Ideal for complex industrial control circuits where reliable timing and fault isolation matter. Long-tail keywords integrated: current-limiting fuse, time-delay protection, dual-element fuse, industrial control protection. Feature: Amperage rating of 1.40A. Business Impact: Precise protection for small-control loads minimizes unnecessary replacements, improving uptime and cost efficiency. Application: Control panels and automation circuits with tight current budgets. Feature: 200 kAIC interrupt rating at 600 Vac (and 20 kAIC at 300 Vdc). Business Impact: High fault tolerance for demanding motor starts and power distribution, reducing cascading failures. Application: Heavy-duty control panels and machine protection. Feature: Rejection style, ferrule end x ferrule end. Business Impact: Prevents incorrect fuse installation, reducing maintenance calls and stocking errors. Application: Field and panel wiring where correct fuse orientation is critical. Feature: Compliance and certifications (CE RoHS, UL Listed, CSA Certified). Business Impact: Regulatory assurance across global projects, simplifying procurement for international deployments. Application: Global automation projects and safety-critical installations. Feature: Material and dimensions (melamine tube, 0.41 in x 0.41 in x 1.5 in, non-indicating). Business Impact: Compact footprint and easy replacement in tight panel spaces, with straightforward identification. Application: Space-constrained control cabinets and modular panels.
Get a Quick Quote for a Eaton LP-CC-1-4/10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-1-4/10?
Enquire Now
FAQs
The LP-CC-1-4/10 uses ferrule-end connections and a Class CC form factor, designed to drop into compatible Bussmann-series panel circuits. Its rejection-style design helps ensure correct orientation, reducing misplacement during panel wiring and simplifying field maintenance in control cabinets.
Key specs include a 1.40 A amperage rating, time-delay operation, and dual-element current limiting. It provides 200 kAIC interrupt rating at 600 Vac and 20 kAIC at 300 Vdc, with a 12-second response at 200% rating, suitable for controlled startup surges in industrial equipment.
Yes. It is rated for 600 Vac, with a 200 kAIC interrupt rating, making it appropriate for protection of heavy-duty control circuits and automated machinery in manufacturing environments while meeting UL Listed and CE RoHS compliance.
The fuse carries UL Listed and CSA Certified markings, as well as CE Marked RoHS compliance, which collectively support regulatory conformity across North American and European installations.
With a non-indicating design, visual inspection is limited. Rely on test points or electrical testing to confirm fault status. The rejection style aids correct replacements, and its time-delay, dual-element design reduces nuisance trips, lowering maintenance frequency and total cost of ownership.
