Eaton LP-CC-1-8/10 fuse - UL Listed, CSA Certified
Part Number: LP-CC-1-8/10
Quick Summary
The Eaton LP-CC-1-8/10 fuse delivers current-limiting, time-delay protection for specialized circuits in industrial control systems. Engineers often struggle with nuisance trips and selecting fuses that tolerate startup surges without sacrificing safety. This device carries UL Listed, CSA Certified, CE marked, and RoHS compliant assurances suitable for regulated environments. With its reliable performance in demanding applications, it supports Class CC fuse compatibility, improves uptime, and enables precise current-limiting protection for panel builders and OEMs. The LP-CC-1-8/10 is designed to withstand industrial conditions, including temperature fluctuations and electrical noise, while maintaining consistent trip characteristics. By aligning with regulatory standards and offering straightforward ferrule-end connections, it reduces installation time and risk of mis-wiring.
Product Information
Extended Description
LP-CC-1-8/10 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 1.8 A, rejection style fuse, interrupting rating of 200 kA at 600 Vac and 20 kA at 300 Vdc
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-1-8/10
UPC
051712180498
EAN
5027590172981
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
1.8A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC at 600 Vac 20 kAIC at 300 Vdc
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 300 Vdc
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
Bussmann series Fuseology
LP-CC Spec Sheet
Feature: Current-limiting time-delay design. Business Impact: Protects equipment from damaging surge energy while allowing controlled startup, reducing arc flash exposure and system downtime. Application: Ideal for specialized circuits and industrial control panels where precise surge tolerance is needed, such as drives and feeders. Feature: Dual-element construction. Business Impact: Enhanced reliability during surge events, minimizing nuisance trips and improving uptime in harsh environments. Application: Motor control circuits and high inrush applications that benefit from robust protection. Feature: High interrupt rating of 200 kAIC at 600 Vac and 20 kAIC at 300 Vdc. Business Impact: Safe fault clearing in demanding AC circuits and DC bus configurations, meeting stringent safety standards. Application: Large drives, CNC machines, and programmable logic controllers in regulated facilities. Feature: Rejection style (anti-substitution). Business Impact: Ensures correct replacement, preserving protective coordination and reducing field mistakes. Application: Panel assemblies and critical control panels where accurate fusing is required. Feature: Compact ferrule-end connections with 0.41 in width/depth and 1.5 in height. Business Impact: Easier insertion, more reliable contacts, and compatibility with tight enclosures, cutting install time. Application: Modern control enclosures and distribution panels with limited space. Feature: Certifications and compliance (UL Listed, CSA Certified, CE Marked, RoHS). Business Impact: Simplified regulatory documentation, faster approvals, and lower compliance risk. Application: Industrial environments demanding traceable, standards-aligned protection.
Get a Quick Quote for a Eaton LP-CC-1-8/10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-1-8/10?
Enquire Now
FAQs
The LP-CC-1-8/10 is designed for specialized circuits and industrial control, offering current-limiting time-delay protection. It is ideal for motor control, drives, feeders, and panels where startup surges occur but fast fault clearing is essential to protect downstream components.
Install the LP-CC-1-8/10 using its ferrule-end x ferrule-end connections. Ensure proper alignment with the panel's terminal blocks, verify correct amperage rating of 1.8 A, and secure with standard holding hardware. The unit’s compact size (0.41 in width/depth, 1.5 in height) eases placement in tight enclosures.
Yes. The LP-CC-1-8/10 is UL Listed and CSA Certified, with CE marking and RoHS compliance. These certifications help satisfy global electrical protection requirements, simplify procurement for regulated industries, and support safe, reliable operation in industrial environments.
Key specs include amperage rating of 1.8 A, voltage rating of 600 Vac / 300 Vdc, and interrupt ratings of 200 kAIC at 600 Vac and 20 kAIC at 300 Vdc. It is a dual-element, time-delay fuse suitable for protection of specialized circuits and industrial controls.
By combining current-limiting protection with a dual-element design and high interrupt ratings, the LP-CC-1-8/10 minimizes equipment damage from faults and startup surges, reduces nuisance trips, and supports longer service intervals. Its rejection style helps maintain correct replacements, improving overall protection integrity and lowering maintenance costs over time.
