Eaton LP-CC-3-1/2 Fuse - UL Listed, 20kAIC, 600 Vac
Part Number: LP-CC-3-1/2
Quick Summary
The Eaton LP-CC-3-1/2 fuse is a current-limiting time-delay device designed for specialized circuits and industrial control. It helps engineers prevent nuisance outages by tolerating inrush while delivering fast fault clearance when faults occur. This product is UL Listed and CSA Certified, CE marked, and RoHS compliant, ensuring broad regulatory alignment across global installations. In addition to reliability, the LP-CC-3-1/2 supports compact panel design with ferrule-end connections, enabling straightforward installation in control panels. For procurement teams, this fuse offers predictable performance, high interrupt ratings, and a proven track record in demanding industrial environments, delivering business value through uptime and compliance.
Product Information
Extended Description
LP-CC-3-1/2 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 3.5 A, rejection style fuse, interrupting rating of 20 kA at 150 Vdc and 200 kA at 600 Vac
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-3-1/2
UPC
051712180306
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
3.5 A
Number of elements
Dual
Class
Class CC
Interrupt rating
20 kAIC at 150 Vdc 200 kAIC at 600 Vac
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 150 Vdc
Feature: Current-limiting time-delay fuse with dual elements. Benefit: Protects wiring and components while tolerating normal inrush, reducing unnecessary outages in motor control and machinery. Application: Ideal for specialized circuits in industrial control panels where selective coordination matters and downtime costs are high. Feature: Rejection style and ferrule end connections. Benefit: Positive fuse placement during manufacturing and easier replacement in confined spaces, improving installation speed and reducing wiring errors. Application: Common in panel boards and compact control architectures that require secure, vibration-resistant terminations. Feature: Class CC, 3.5 A rating. Benefit: Precise overcurrent protection tailored to small- to mid-size loads, delivering targeted protection with predictable trip behavior. Application: Motor starters, control relays, and signal circuits in automation systems where space is at a premium. Feature: High interrupt ratings — 20 kAIC at 150 Vdc and 200 kAIC at 600 Vac. Benefit: Robust fault-clearing capability for high-energy faults, improving system safety and reducing collateral damage. Application: Industrial power distribution and critical control circuits in manufacturing plants. Feature: Compliance and certifications — CE Marked, RoHS, UL Listed, CSA Certified. Benefit: Streamlined qualification and regulatory acceptance across multiple regions, reducing time-to-deploy and audit findings. Application: Global deployments in machinery, packaging, and process automation. Feature: Physical specs — 1.5 in length, 0.41 in height and width, ferrule-to-ferrule end, 0.15 lb weight. Benefit: Compact form factor supports dense panel layouts and straightforward replacement. Application: Control panels with tight spatial constraints and standardized ferrule terminations.
Get a Quick Quote for a Eaton LP-CC-3-1/2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-3-1/2?
Enquire Now
FAQs
The LP-CC-3-1/2 is designed for specialized circuits and industrial control applications, including motor starters and control relays. Its current-limiting time-delay design tolerates inrush currents while providing fast fault clearing, helping protect wiring and components in compact panels where space and reliability are critical.
Key specs include a 3.5 A amperage rating, dual-element current-limiting time-delay design, 20 kAIC interrupt rating at 150 Vdc, and 200 kAIC at 600 Vac, with a 600 Vac/150 Vdc rating. It uses ferrule-to-ferrule connections and measures 1.5 inches in length with a 0.41 inch square cross-section.
Yes. The LP-CC-3-1/2 features ferrule end x ferrule end connections, which facilitates straightforward insertion and replacement in standard control panels. Its compact 1.5 inch body fits in tight spaces, and its rejection-style design aids reliable placement during assembly.
The fuse is UL Listed and CSA Certified, with CE marking and RoHS compliance. This combination supports regulatory acceptance in North America and international markets, simplifying approvals for machines, packaging lines, and process automation equipment.
By delivering selective protection with fast fault clearing, the LP-CC-3-1/2 reduces downtime and collateral damage, lowering maintenance costs. Its standardized form factor and robust certifications streamline procurement and stocking, improving uptime and return on investment in high-demand automation environments.
