Eaton LP-CC-3-2/10 Fuse - UL Listed 200 kAIC Class CC
Part Number: LP-CC-3-2/10
Quick Summary
LP-CC fuse in the Eaton Bussmann Series provides time-delay current-limiting protection for industrial control circuits. Selecting the right fuse for mixed loads and ensuring fast yet safe interruption when faults occur can slow projects. UL Listed and CSA Certified, with CE Marked RoHS compliance, these certifications support safety, interoperability, and regulatory alignment across regions. This Class CC dual-element fuse is engineered for specialized circuits and industrial control, delivering predictable discrimination and robust fault current handling. Lightweight and compact, it helps streamline panel layouts while meeting global safety standards, reducing downtime and maintenance costs for OEMs and integrators.
Product Information
Extended Description
LP-CC-3-2/10 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 3.2 A, rejection style fuse, interrupting rating of 200 kA at 600 Vac and 20 kA at 150 Vdc
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-3-2/10
UPC
051712180351
EAN
5027590101356
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
3.2 A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC at 600 Vac 20 kAIC at 150 Vdc
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 150 Vdc
Time-delay, dual-element current-limiting design provides selective protection for motors and control circuits. This approach reduces nuisance tripping and shortens fault-clearing times, improving machine uptime and overall line efficiency. Ideal for motor starters, contactor circuits, and PLC panels in manufacturing environments where reliability and fast fault discrimination matter. Rejection style construction prevents accidental substitution with the wrong amperage, lowering field errors and warranty risk while delivering correct protection in critical circuits. High interrupt ratings of 200 kAIC at 600 Vac and 20 kAIC at 150 Vdc minimize equipment damage during short circuits, supporting safety margins in high-energy systems. Ferrule-end connections and a compact 0.41 in × 0.41 in cross-section with 1.5 in height simplify installation in tight panels and small enclosures. Certifications including UL Listed, CSA Certified, and CE RoHS compliance streamline global sourcing and regulatory alignment for OEMs. Standard packaging of ten units per pack supports stocking and maintenance efficiency for service teams across multiple facilities.
Get a Quick Quote for a Eaton LP-CC-3-2/10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-3-2/10?
Enquire Now
FAQs
The LP-CC-3-2/10 uses ferrule-end connections and a compact footprint (0.41 in width, 0.41 in depth, 1.5 in height). This design simplifies panel mounting, reduces insertion torque, and minimizes space requirements in compact control enclosures. Ensure compatible ferrule terminals are used and verify that the enclosure supports a Class CC fuse footprint for proper discrimination in protection schemes.
Key specs include a 3.2 A amperage rating, 600 Vac and 150 Vdc voltage ratings, time-delay current-limiting behavior, dual-element construction, and a 200 kAIC interrupt rating at 600 Vac plus 20 kAIC at 150 Vdc. The fuse is non-indicating, with a rejection-style design to prevent incorrect replacements and a Class CC classification for standardized size and performance.
Best suited for specialized circuits and industrial control applications such as motor starters, PLC panels, and other control circuits with mixed loads. The dual-element time-delay behavior helps accommodate inrush while protecting downstream devices, and the high interrupt ratings provide robust protection against short-circuit events, making it ideal for high-energy environments.
The LP-CC-3-2/10 is UL Listed and CSA Certified, with CE Marking and RoHS compliance. These certifications support safety validation, regulatory conformity across North America and Europe, and environmentally responsible manufacturing practices, which is important for global product approvals and supplier qualifications.
With its time-delay, current-limiting design and high interrupt ratings, the fuse minimizes nuisance trips and equipment damage, improving machine uptime and reducing unplanned downtime. The rejection-style feature lowers installation errors, reducing warranty claims. Packaging of ten units per pack simplifies stocking, enabling faster replacements and lower maintenance costs for service teams.
