Eaton LP-CC-5-6/10 Fuse - 200 kAIC UL Listed
Part Number: LP-CC-5-6/10
Quick Summary
Eaton LP-CC-5-6/10 fuse provides current-limiting protection for specialized industrial control circuits. Engineers often struggle with nuisance trips and delayed fault isolation that disrupt production and maintenance scheduling. This device is CE marked, UL Listed, and CSA Certified with RoHS compliance, ensuring regulatory alignment across global installations. The dual-element, time-delay design delivers reliable coordination in control panels, MCCs, and equipment racks, while the ferrule-end connections simplify wiring. By selecting this LP-CC fuse, you gain consistent protection, reduced downtime, and easier panel assembly in demanding industrial environments.
Product Information
Extended Description
LP-CC-5-6/10 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 5.6 A, rejection style fuse, interrupting rating of 200 kA at 600 Vac and 20 kA at 150 Vdc
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-5-6/10
UPC
051712180511
EAN
5027590447027
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
5.60A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC at 600 Vac 20 kAIC at 150 Vdc
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 150 Vdc
Feature: Current-limiting time-delay fuse with dual elements → Benefit: Fast fault isolation with selective clearing reduces collateral damage and downtime in demanding circuits. Application: Specialized industrial control panels and MCCs where precise coordination matters. Feature: 5.6 A amperage rating → Benefit: Proper protection for circuits with predictable loads, lowering fuse nuisance trips while maintaining safety. Application: Control circuits and relays in manufacturing lines. Feature: High interrupt rating (200 kAIC at 600 Vac; 20 kAIC at 150 Vdc) → Benefit: Superior fault current handling in high-energy systems, improving equipment resilience and plant uptime. Application: Main and feeder protection in heavy panels and motor-control centers. Feature: Rejection style with ferrule ends → Benefit: Reduced installation errors and secure, vibration-resistant connections. Application: Easy retrofits and clean panel wiring in compact enclosures. Feature: Compliance and certifications (UL Listed, CSA Certified, CE RoHS) → Benefit: Seamless regulatory approval and global deployment across facilities. Application: Modern safety-compliance programs and cross-border projects. Feature: Class CC, time-delay, current-limiting characteristics → Benefit: Optimized coordination with downstream protection devices, minimizing blackout risk. Application: Industrial control and machinery protection in automation systems.
Get a Quick Quote for a Eaton LP-CC-5-6/10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-5-6/10?
Enquire Now
FAQs
Install the LP-CC-5-6/10 with ferrule-end conductors and matching Class CC fuse holders. Use two ferrule-end leads per end of the fuse as specified, ensure clean, tight terminations, and verify compatibility with the panel’s busbar spacing. This design reduces wiring errors and improves vibration resistance in industrial enclosures.
The fuse is rated at 5.6 A with current-limiting, dual-element construction and a time-delay response. It provides an interrupt rating of 200 kAIC at 600 VAC and 20 kAIC at 150 VDC, with a specified response of 12 seconds at 200% overcurrent, enabling selective protection in complex circuits.
Yes. The LP-CC-5-6/10 is specified for 600 VAC and 150 VDC operation, making it suitable for mixed-voltage panels and industrial drives where AC line protection and DC fault current considerations must be coordinated within the same enclosure.
This fuse is UL Listed, CSA Certified, and CE marked with RoHS compliance. These certifications help you meet electrical safety standards, support global deployments, and simplify procurement during audits and regulatory reviews for multinational projects.
Choosing the LP-CC-5-6/10 reduces downtime via reliable fault clearing, minimizes nuisance trips with time-delay coordination, and simplifies panel wiring with ferrule-end connections. The result is improved uptime, predictable maintenance windows, and a stronger return on investment for critical automation infrastructure.
