Eaton LP-CC-7-1/2 Fuse - Current-Limiting Time-Delay, UL Listed
Part Number: LP-CC-7-1/2
Quick Summary
The Eaton LP-CC-7-1/2 fuse is a current-limiting time-delay device designed for industrial control circuits. This fuse delivers reliable protection during startup and fault conditions, reducing arc energy and equipment damage. It carries UL Listed, CSA Certified, and CE Marked RoHS compliance to support global installations and safety programs. By combining dual-element protection with a rejection-style format, it minimizes nuisance trips while maintaining fast fault clearance. Built for controlled panels and machine builds, this component supports factory uptime and predictable maintenance cycles, aligning with lean reliability goals and lower total cost of ownership in electrical protection strategies. In short, it pairs robust protection with practical procurement and installation benefits for modern automation environments.
Product Information
Extended Description
LP-CC-7-1/2 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 7.25 A, rejection style fuse, interrupting rating of 20 kA at 150 Vdc and 200 kA at 600 Vac
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-7-1/2
UPC
051712180382
EAN
5027590447034
Product Length/Depth
0.41 in
Product Height
1.5 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
7.5 A
Number of elements
Dual
Class
Class CC
Interrupt rating
20 kAIC at 150 Vdc 200 kAIC at 600 Vac
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 150 Vdc
Feature: Current-limiting time-delay fuse with dual elements. Business Impact: Reduces thermal stress on conductors, limits arc flash energy during faults, and minimizes downtime. Application: Ideal for specialized circuits and industrial control panels where inrush is common. Feature: Rejection style design. Business Impact: Prevents incorrect installation and misrouting of fuses, lowering maintenance calls. Application: Critical in multi-fuse panels with stringent fit-and-in function requirements. Feature: 7.5 A amperage rating and 12-second response at 200% overload. Business Impact: Accurate protection for motors and control loads without nuisance trips, improving equipment longevity. Application: Motor starters and control circuits in packaging, material handling, and process lines. Feature: High interrupt ratings: 20 kAIC at 150 Vdc and 200 kAIC at 600 Vac. Business Impact: Enhanced safety margins for short-circuit events and higher inrush scenarios. Application: Heavy control panels and machines with demanding surge environments. Feature: Ferrule end connections and compact form factor. Business Impact: Easy panel integration, quick replacement, and consistent electrical connections. Application: Standardized in Bussmann LP-CC families and new installations alike. Feature: Compliance and certifications (UL Listed, CSA Certified, CE RoHS). Business Impact: Supports global regulatory readiness, supplier qualification, and risk reduction. Application: Global manufacturing lines and multi-region deployments. The combination of these features supports predictable performance, reduced maintenance, and faster, compliant panel builds for industrial automation projects.
Get a Quick Quote for a Eaton LP-CC-7-1/2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-7-1/2?
Enquire Now
FAQs
Install with ferrule end x ferrule end connections in panels designed for Class CC fuses. The LP-CC-7-1/2 has a compact 0.41 in width and 1.5 in height, and ships in standard packaging of ten pieces. Ensure panel cutouts and bus bar clearances meet Eaton Bussmann guidelines and that the fuse is oriented for reliable heat dissipation and easy replacement.
The fuse is a dual-element, current-limiting time-delay device rated at 7.5 A. It provides 20 kAIC interrupt rating at 150 Vdc and 200 kAIC at 600 Vac, with a 12-second response time at 200% overload. The voltage rating covers 600 Vac and 150 Vdc, appropriate for industrial control circuits.
Yes. The time-delay design accommodates inrush currents typical of motors and control relays, while the current-limiting feature protects wiring and components from high fault energy. The dual-element construction helps sustain fault tolerance without unnecessary tripping during startup.
This fuse carries UL Listed and CSA Certified marks, along with CE Marked RoHS compliance. These certifications support compliance with North American and European standards, simplify supplier qualification, and align with regulatory requirements for industrial equipment.
The LP-CC-7-1/2 reduces downtime through consistent protection and fast fault clearance, lowers maintenance calls via rejection-style installation, and supports global deployments with UL/CSA/CE RoHS compliance. Its 10-per-pack packaging and manageable weight aid inventory planning and spares strategy for industrial automation assets.
