Eaton LP-CC-8/10 Fuse - Class CC current-limiting, UL Listed
Part Number: LP-CC-8/10
Quick Summary
Introducing the Eaton LP-CC-8/10 fuse, a Class CC current-limiting, time-delay device designed for specialized circuits and industrial control panels. The core challenge in automation protection is balancing fast fault clearing with tolerance for inrush and startup surges. This fuse addresses nuisance trips and selective coordination via a dual-element design that withstands brief overloads while protecting downstream equipment. UL Listed, CSA Certified, CE marked, and RoHS compliant certifications provide clear regulatory alignment for North American and European operations. The compact ferrule-end construction streamlines installation and reduces panel space, while the 0.8 A rating and high interrupt ratings support safe, reliable operation in demanding environments.
Product Information
Extended Description
LP-CC-8/10 Eaton: Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 0.8 A, rejection Style fuse, interrupting rating of 200 kA at 600 Vac and 20 kA at 150 Vdc
Product Name
Eaton Bussmann series LP-CC fuse
Catalog Number
LP-CC-8/10
UPC
051712180429
Product Length/Depth
1.5 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Type
Current-limiting time-delay fuse
Special features
Rejection style
Application
Specialized circuits and industrial control
Amperage Rating
0.8 A
Number of elements
Dual
Class
Class CC
Interrupt rating
200 kAIC at 600 Vac 20 kAIC at 150 Vdc
Fuse indicator
Non-indicating
Connection
Ferrule end x ferrule end
Response time
12 sec at 200%
Material
Melamine tube
Packaging type
Standard
Quantity
10
Voltage rating
600 Vac, 300 Vdc
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
Bussmann series Fuseology
LP-CC Spec Sheet
Feature is a current-limiting time-delay dual-element fuse that minimizes fault energy and limits arc exposure. Business impact is safer startups, extended equipment life, and reduced downtime, enabling smoother operation of specialized circuits and industrial control panels. Application centers on controlled protection for feeders, relays, and automation devices in demanding environments. Feature highlights include a dual-element design that tolerates inrush yet clamps faults quickly, improving selectivity and reducing collateral damage. Application fits industrial control cabinets where startup surges are common and precise protection is required. Feature also includes a rejection-style design that prevents incorrect insertion, increasing installation reliability. Business impact is faster maintenance and fewer field errors. Application spans automation assemblies, machine control panels, and Kardex/line-side protection. Feature supports ferrule-end connections for straightforward wiring and reliable terminations, reducing termination time and errors. Business impact is faster assembly and easier compliance auditing. Application covers UL CSA CE RoHS-certified products that meet global standards, enabling cross-border deployment. Feature emphasizes a compact form factor, 1.5 inch length and 0.41 inch dimensions, which save panel area. Business impact is space optimization and easier retrofits in retrofit or expansion projects. Application includes 0.8 A rating with 200 kAIC interrupt rating at 600 Vac and 12 second response at 200%, delivering robust protection for specialized circuits and industrial control without overfusing devices.
Get a Quick Quote for a Eaton LP-CC-8/10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton LP-CC-8/10?
Enquire Now
FAQs
Power must be OFF before handling. Use ferrule-end connections as specified (Ferrule end x ferrule end) and ensure compatibility with Bussmann series holders. Confirm the catalog number LP-CC-8/10, then insert straight into the appropriate fuse holder, verifying solid contact. Since this is a non-indicating fuse, use a meter or panel indication strategy to confirm operation after installation.
Amperage rating is 0.8 A with a current-limiting time-delay design. Voltage rating is 600 Vac and 300 Vdc. It is a dual-element class CC fuse with a 200 kAIC interrupt rating at 600 Vac and 20 kAIC at 150 Vdc. The fusion time is approximately 12 seconds at 200% overload; connections are ferrule ends.
The LP-CC-8/10 is intended for specialized circuits and industrial control, offering inrush tolerant, current-limiting protection. For motor protection, verify motor starting currents and circuit protection coordination. While useful for contactors and control circuits, large motor loads typically require higher ratings; consult the catalog and perform coordination studies to ensure proper selectivity.
The LP-CC-8/10 carries UL Listed and CSA Certified marks, with CE Marked and RoHS Compliant labeling. These certifications support compliance across North American and European markets, simplifying procurement and regulatory validation for industrial automation projects.
Stock a standard quantity of 10 per package for quick replacements and service continuity. Since the LP-CC-8/10 is non-indicating, keep spare fuses accessible and implement a periodic verification process. Replace after a fault event or at scheduled maintenance according to system protection coordination guidelines and the equipment’s service intervals.
