Eaton MIC-10 Fuse - 200 AIC at 250 Vac, CE Marked
Part Number: MIC-10
Quick Summary
The Eaton MIC-10 fuse is a fast-acting microminiature fuse designed for control circuits and PLC interfaces in industrial panels. Engineers often face nuisance trips and time-consuming replacement in tight enclosures, compromising uptime. This part carries CE marking for regulatory compliance and offers a robust 200 AIC interrupt rating at 250 V, aligning with IEC/UL expectations. With ferrule-end connections and a compact 0.47 inch depth, it delivers reliable protection while simplifying installation in control cabinets. For teams pursuing compliant, cost-effective protection across PLCs, electronic circuits, and control systems, MIC-10 provides a proven balance of performance and value.
Product Information
Extended Description
MIC-10 Eaton: Eaton Bussmann series MIC fuse, Fast acting, Midget fuse, Control circuits, PLC circuits, Electronic circuits, 10 A, Non-indicating, Ferrule end x ferrule end, 200 AIC at 250 Vac, Nickel-plated bronze endcap, Fiber tube, Standard, 250 V
Product Name
Eaton Bussmann series MIC fuse
Catalog Number
MIC-10
UPC
051712726467
EAN
5027590450164
Product Length/Depth
0.47 in
Product Height
1.813 in
Product Width
0.47 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
10 A
Interrupt rating
200 AIC at 250 Vac
Voltage rating
250 V
Material
Fiber tube Nickel-plated bronze endcap
Packaging type
Standard
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - MIC-10
Feature: Fast-acting 10 A fuse with a 200 AIC interrupt rating at 250 V. Business Impact: Quick fault isolation reduces arc energy, protecting sensitive control electronics and minimizing downtime in automation lines. Application: Ideal for control circuits and PLC interfaces where fast clearing improves system reliability and uptime. Feature: Non-indicating design. Business Impact: Reduces panel clutter and avoids misinterpretation from indicator LEDs, lowering maintenance complexity. Application: Used in compact control panels and machine cabinets with external status monitoring. Feature: Ferrule-end x ferrule-end connections. Business Impact: Easy, secure replacement with common fuse holders, reducing service time and wiring mistakes. Application: Standard industrial equipment fusing for easy retrofits. Feature: Nickel-plated bronze endcaps on a fiber tube. Business Impact: Improves durability and corrosion resistance in harsh environments, extending service life. Application: Industrial automation environments with vibration and temperature variation. Feature: Standard packaging and 0.47 in depth. Business Impact: Fits tight panel depths and streamlines procurement and stock management. Application: Dense electrical protection schemes in control cabinets and MCCs. The MIC-10 integrates seamlessly with the Eaton Bussmann MIC fuse family and supports long-term reliability, compliance, and total cost of ownership considerations for modern manufacturing facilities.
Get a Quick Quote for a Eaton MIC-10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton MIC-10?
Enquire Now
FAQs
MIC-10 uses ferrule end-to-end connections and is designed for standard fuse holders used with Bussmann MIC series. It fits common DIN rail and panel-mounted blocks that accept ferrule-end fuses, ensuring straightforward replacement in existing control cabinets. For best results, refer to Eaton compatibility charts and verify endcap diameter and mounting clearance before installation.
MIC-10 is rated for 10 A with a 200 AIC interrupt rating at 250 Vac and a voltage rating of 250 V. This means it can safely interrupt faults up to 200 A at up to 250 V, protecting control circuits, PLC interfaces, and electronic circuits from overcurrent events while maintaining safe operation within standard industrial voltages.
Yes. The MIC-10 is specifically designed for control circuits and PLC circuits, offering fast-acting protection with a compact form factor. Its ferrule-end design and fiber-tube construction support reliable performance in dense panel layouts, contributing to improved machine uptime and predictable protection for automation components.
MIC-10 carries CE Marking, indicating regulatory compliance for European markets. This certification supports safety and performance expectations in global deployments. While other certifications are not listed in the provided data, CE marking ensures alignment with essential EU directives for electrical equipment used in automation and control systems.
The non-indicating design reduces panel clutter and removes signal indicators that can wear or fail, simplifying visual inspection. Maintenance relies on external monitoring of fuse status via the control system or diagnostic tools, which can improve reliability and uptime while lowering replacement costs and field service time over the life of an automation line.
