Eaton N3024P Panel Enclosures - NEMA 3R Type 3R
Part Number: N3024P
Quick Summary
Eaton N3024P is a wall-mounted panel enclosure designed to protect electrical gear in outdoor or semi-exposed installations. When rain, sleet, or ice threaten uptime, you need rugged protection that doesn’t complicate service or expansion. UL Listed, CSA C22.2, and NEMA 3R ratings provide code-aligned reliability for harsh environments, while the ANSI 61 gray galvanized steel construction supports long-term durability. This enclosure integrates with Eaton B-Line accessories to streamline installation and lifecycle management, delivering a dependable, weather-resistant solution for commercial and industrial facilities.
Product Information
Extended Description
N3024P Eaton: Eaton B-Line series panel enclosure, NEMA 3R, ANSI 61 gray painted, Protects against rain, sleet and ice formation, Galvanized steel, Wall mounting, Panel enclosures, Type 3r large continuous hinge cover, 30" X 24" panel
Product Name
Eaton B-Line series panels and panel accessories
Catalog Number
N3024P
UPC
782051377064
Product Length/Depth
20.875 in
Product Height
26.87 in
Product Width
0.75 in
Product Weight
17.379 lb
Certifications
UL Listed CSA C22.2. NEMA
Application
Protects against rain, sleet and ice formation
Material
Galvanized steel
Finish color
ANSI 61 gray painted
Mounting method
Wall
Product Category
Panel enclosures
Type
Type 3r large continuous hinge cover
Degree of protection
NEMA 3R
Weather-resistant protection meets real-world reliability. Feature → Business Impact → Application: The NEMA 3R rating combined with galvanized steel construction reduces corrosion risk and weather-induced downtime, increasing panel life in outdoor installations and harsh environments. This translates to lower maintenance costs and fewer unplanned outages for facilities with outdoor electrical panels and controls. Feature → Business Impact → Application: Large 30" x 24" panel opening enables easier field modification and easier integration of multiple breakers and accessories, accelerating commissioning in manufacturing lines and building automation projects. Feature → Business Impact → Application: Type 3R large continuous hinge cover delivers durable sealing and smooth door operation, minimizing service interruptions during frequent access in data centers or utility rooms, and supporting compliant enclosure maintenance. Feature → Business Impact → Application: Wall mounting with ANSI 61 gray painted finish provides a clean, code-compliant appearance while simplifying retrofits and upgrades in retrofit projects. Feature → Business Impact → Application: UL Listed, CSA C22.2, and NEMA certifications support regulatory compliance and contractor acceptance, reducing procurement risk in regulated facilities. Feature → Business Impact → Application: Galvanized steel construction offers robust impact resistance and long-term weatherproofing in outdoor kiosks, switchgear houses, and outdoor control panels.
Get a Quick Quote for a Eaton N3024P
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton N3024P?
Enquire Now
FAQs
To install the N3024P, mount the enclosure on a suitable wall surface using compatible anchors and fasteners. Ensure the wall has adequate support for the 17.379 lb unit weight and align the enclosure with service access clearance. Connect field wiring through approved conduit entries and secure the Type 3R large continuous hinge cover to maintain NEMA 3R protection while providing easy access for maintenance.
Key specs include a 20.875 in depth, 26.87 in height, 30 x 24 in panel opening, and a 17.379 lb weight. The enclosure is constructed from galvanized steel with ANSI 61 gray finish and provides NEMA 3R protection. It carries UL Listed and CSA C22.2 certifications, supporting robust outdoor or storm-prone applications.
Yes. The N3024P is designed for rain, sleet, and ice formation protection with NEMA 3R protection, making it well-suited for outdoor panels and exposed indoor locations. Its galvanized steel construction and weather-resistant finish reduce corrosion and downtime, while the large hinge cover simplifies weatherproofing during routine access and maintenance.
This enclosure is UL Listed and CSA C22.2 certified, aligning with common North American electrical codes. The NEMA 3R rating confirms weather-resistant performance for outdoor and semi-exposed environments. Together, these certifications support code compliance, contractor acceptance, and safer, more reliable installations.
Choosing the N3024P delivers reduced maintenance cycles due to weatherproof galvanization and durable hardware, lowering total cost of ownership. The large panel opening simplifies retrofits and expansions, shortening downtime during upgrades. Combined with reliable UL and CSA certifications, facilities experience fewer outages and faster commissioning on outdoor or harsh-environment projects.
