Eaton N86P Panel Enclosures - NEMA 1, ANSI 61 Gray
Part Number: N86P
Quick Summary
N86P is an Eaton panel enclosure designed to house electrical controls and instruments in industrial environments. Engineers often struggle with durable, code-compliant enclosures that fit tight control panels and resist field conditions. It meets NEMA 1 protection with UL Listed and CSA C22.2 certifications, ensuring safe operation in standard electrical rooms. Steel construction combined with ANSI 61 gray paint supports long service life and predictable maintenance costs. Its compact footprint also reduces cabinet real estate while enabling fast installation with standard panel accessories. N86P is well suited for control housings in manufacturing, utilities, and process industries. This combination helps maintenance teams shorten mean time to repair and drive safer, more reliable operations.
Product Information
Extended Description
N86P Eaton: Eaton B-Line series panel enclosure, NEMA 1, ANSI 61 gray painted, Used to houses electrical controls and instruments, Steel, Panel enclosures, Type 1 locking enclosure with perforated panel
Product Name
Eaton B-Line series panels and panel accessories
Catalog Number
N86P
UPC
782051377217
Product Length/Depth
4.25 in
Product Height
6.25 in
Product Width
0.063 in
Product Weight
0.537 lb
Certifications
NEMA CSA C22.2. UL Listed
Application
Used to house electrical controls and instruments
Material
Steel
Finish color
ANSI 61 gray painted
Product Category
Panel enclosures
Type
Type 1 small
Degree of protection
NEMA 1
NEMA 1 protection with steel construction delivers durable containment for control circuits. It reduces downtime by shielding electronics from dust, moisture, and incidental contact in routine industrial environments. The Type 1 small enclosure is suitable for compact control panels where space is at a premium. It is well suited for machine control panels and instrumentation housings across manufacturing lines, utilities, and process plants. ANSI 61 gray painted finish offers consistent maintenance and plant-wide aesthetics. The durable coating resists scuffs during servicing, simplifies touch-up painting, lowering repaint costs during retrofits. The gray finish also helps with visibility and heat reflection, supporting safer equipment upkeep in cramped cabinets. It supports compliance with internal standards where color-coding or finish uniformity is required. Compact footprint and lightweight form factor streamline installation. The 4.25 in depth by 6.25 in height and 0.063 in width balance cabinet density with service access, while a weight of 0.537 lb eases handling. Perforated panel with a Type 1 locking enclosure accelerates wiring, cable management, and secure access for routine maintenance. The design supports quick retrofits by enabling straightforward accessory mounting from the Eaton B-Line catalog. UL Listed and CSA C22.2 certifications provide regulatory assurance. This compliance minimizes audit risk and supports safe operation in standard electrical rooms. NEMA 1 protection ensures basic ingress protection for indoor installations. When combined with Eaton B-Line accessories, you gain scalable installation options and proven compatibility. Compatibility and lifecycle value: Access to the B-Line panel ecosystem reduces engineering time and procurement complexity. Standardized mounting patterns and available accessories translate to faster deployment, lower total cost of ownership, and longer service life in industrial environments. The N86P leverages common components and widely supported service networks to simplify maintenance.
Get a Quick Quote for a Eaton N86P
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton N86P?
Enquire Now
FAQs
The N86P is a Type 1 small panel enclosure with a perforated panel and a locking mechanism, designed for straightforward mounting in standard electrical rooms. Its compact 4.25 in depth and 6.25 in height fit alongside existing backplanes, and it accommodates Eaton B-Line panel accessories for quick integration with current control systems.
NEMA 1 protection delivers basic enclosure ingress protection suitable for indoor, controlled environments. For machine tooling, control cabinets, and instrument housings, this protects against dust and incidental contact, supporting reliable operation and reduced maintenance in standard manufacturing and process facilities.
N86P carries NEMA 1 protection and is UL Listed, CSA certified, and designed for indoor use. It is not rated for hazardous or demanding environments requiring explosion-proof or higher IP ratings; for those settings, higher-spec enclosures should be selected to meet applicable safety standards.
N86P is UL Listed and CSA C22.2 certified, with NEMA 1 protection. These certifications validate electrical safety, compliance with regional standards, and suitability for assembly with other components in the Eaton B-Line enclosure ecosystem, reducing risk during audits and aiding regulatory approvals.
Selecting N86P leverages Eaton's B-Line accessories for standardized mounting, which shortens engineering and installation time. The steel, durable finish reduces repaint cycles and downtime, while UL/CSA certifications simplify compliance. Together these factors lower total cost of ownership and improve equipment uptime in industrial facilities.
