Eaton NGS408035M MCCB - METRIC TAPPED TERMINALS
Part Number: NGS408035M
Quick Summary
The Eaton NGS408035M MCCB provides reliable overcurrent protection for electrical panels. Engineers often struggle with wiring complexity, space constraints, and reliable terminal connections when configuring Series G four-pole protection. This model delivers a compact 1 x 1 x 1 in footprint with METRIC TAPPED TERMINALS, helping to reduce wiring errors and installation time in crowded control panels. Compliances are listed as 'Contact Manufacturer' in the datasheet, so verify applicable standards such as CE markings, IP ratings, and SIL considerations with Eaton for your market. For factory and process environments, Series G MCCBs support high-current protection with straightforward upgrade paths, delivering improved uptime and safer shutdowns while keeping peripheral wiring streamlined and cost-effective.
Product Information
Extended Description
NGS408035M Eaton: Eaton Series G molded case circuit breaker, NGS 310+ 4P, 800A, LSG, METRIC TAPPED TERMINALS
Product Name
Eaton Series G molded case circuit breaker
Catalog Number
NGS408035M
UPC
786685939773
Product Length/Depth
1 in
Product Height
1 in
Product Width
1 in
Product Weight
1 lb
Compliances
Contact Manufacturer
Type
Series G
Special features
Molded case circuit breaker
