Eaton NGS408036EC Molded Case Circuit Breaker - 100% RATED
Part Number: NGS408036EC
Quick Summary
Eaton Series G molded case circuit breaker protects electrical distribution panels and machinery by interrupting fault currents. Engineers often face nuisance trips, undersized protection, and downtime when wiring in crowded panels. While exact certifications should be confirmed with Eaton, many users seek SIL-rated, CE-compliant, or IP-rated protection for critical infrastructure. The NGS408036EC delivers a compact 1x1x1 in footprint with an 800 A rating, helping simplify panel layouts without compromising reliability. This model aligns with typical electrical protection workflows and supports robust protection coordination and maintenance planning for industrial environments.
Product Information
Extended Description
NGS408036EC Eaton: Eaton Series G molded case circuit breaker, NGS 310+ 4P, 800A, LSIG, ENGLISH TAPPED TERMS, 100% RATED
Product Name
Eaton Series G molded case circuit breaker
Catalog Number
NGS408036EC
UPC
786685939940
Product Length/Depth
1 in
Product Height
1 in
Product Width
1 in
Product Weight
1 lb
Compliances
Contact Manufacturer
Type
Series G
Special features
Molded case circuit breaker
