Eaton NON-1 Fuse - Class H, 1 A, 50 kAIC CE Marked
Part Number: NON-1
Quick Summary
The Eaton NON-1 fuse provides reliable general-purpose protection for control panels and branch circuits in industrial automation. In busy cabinets, nuisance trips can drive maintenance costs and downtime; this non-current-limiting fuse helps maintain uptime by avoiding unnecessary interruptions in simple, fault-tolerant designs. CE marking confirms European safety compliance, and the Class H construction ensures predictable performance in small, high-impedance circuits. The device offers a 1 A rating with a 50 kAIC interrupt capability at both 125 VDC and 250 VAC, making it suitable for mixed AC/DC protection. Its ferrule-end connections and compact footprint support quick installation and scalable panel layouts while preserving Bussmann/Eaton reliability.
Product Information
Extended Description
NON-1 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 1 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-1
UPC
051712300018
EAN
5027590065269
Product Length/Depth
0.56 in
Product Height
2 in
Product Width
0.56 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
1 A
Interrupt rating
50 kAIC at 125 Vdc 50 kAIC at 250 Vac
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature: Non-current-limiting design. Benefit: Reduces nuisance trips in non-critical loads, improving uptime and maintenance predictability. Application: General protection in control panels and automation cabinets where simple loads are protected without aggressive current limiting. Feature: High interrupt rating of 50 kAIC at 125 Vdc and 250 Vac. Benefit: Robust fault handling for high-energy circuits, enhancing system safety and reducing fire risk. Application: Power feeds and machine controls exposed to high fault currents in industrial environments. Feature: 1 A amperage rating. Benefit: Precise protection for small loads gives dependable selective tripping and protects sensitive control circuits. Application: Control electronics, signaling, and logic modules in automation cells. Feature: Ferrule-end x ferrule-end connection. Benefit: Easy, secure installation with standard fuse blocks, minimizing commissioning time. Application: Any panel using ferrule-end Bussmann/Eaton fuses and compatible holders. Feature: Class H format and non-indicating fuse. Benefit: Predictable coordination with standard protection schemes and reduced visual distraction in dense panels. Application: General protection in compact control enclosures and low-profile assemblies. Feature: Compact dimensions and weight (0.56 in L, 0.56 in W, 2 in H; 0.35 lb). Benefit: Space-efficient mounting and simplified inventory management for multi-sku panels. Application: Modern machine cabinets and modular panel designs. Feature: Compliance and packaging details (CE Marked, standard packaging, 10 units per pack). Benefit: Streamlined procurement, consistent stock, and regulatory alignment for European installations. Application: OEMs and panel builders seeking reliable, ready-to-assemble protection components.
Get a Quick Quote for a Eaton NON-1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-1?
Enquire Now
FAQs
The NON-1 fuse uses ferrule-end connections compatible with standard fuse blocks and Bussmann/Eaton protection blocks. It suits compact control panels, automation cabinets, and other DIN-rail or fixed-mocket assemblies where ferrule-end fuses are the standard. Ensure the holder accepts Class H, ferrule-end fuses and check the block’s pitch and contact rating for reliable clamping and heat dissipation.
The fuse is rated at 1 A with an interrupt rating of 50 kAIC at 125 Vdc and 50 kAIC at 250 Vac. It uses a 250 Vac / 125 Vdc voltage rating, and is a non-current-limiting Class H fuse. Such specs support reliable protection in mixed AC/DC control circuits while minimizing nuisance trips in simple loads.
Yes. Its 1 A rating, high interrupt capacity, and non-current-limiting behavior make it appropriate for general protection in machine controls and automation panels. It pairs well with ferrule-end block assemblies and is compact enough for dense panel layouts, helping maintain uptime in manufacturing environments.
The NON-1 fuse carries CE Marking, indicating compliance with European safety standards. This is important for any European-installed equipment and industrial systems that require regulatory alignment. While UL/CSA markings are common, this product’s documentation specifies CE compliance and Class H characteristics for coordination in protection schemes.
By reducing nuisance trips through non-current-limiting protection, the NON-1 fuse lowers unnecessary shutdowns and maintenance interventions in simple automation circuits. Its easy ferrule-end installation speeds replacements, and the compact footprint supports scalable panel designs, contributing to lower inventory costs and faster service in high-volume production environments.
