Eaton NON-1-6/10 Fuse - Class H, 50 kAIC
Part Number: NON-1-6/10
Quick Summary
Eaton Bussmann NON fuse provides general-purpose protection for control panels and automation circuits. Engineers often struggle to balance continuous operation with reliable interruption during faults, especially in crowded panel environments. This Class H NON fuse delivers a 1.6 A rating with a robust 50 kA interrupt capacity at 250 Vac and 125 Vdc, and it carries CE Marking for international compliance. The combination of non-current-limiting behavior and standard Bussmann Series compatibility translates to predictable protection, streamlined procurement, and better lifecycle costs for industrial automation projects. Use cases span instrumentation, I/O protection, and small drive circuits where dependable, easy-to-source fusing matters most.
Product Information
Extended Description
NON-1-6/10 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 1.6 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-1-6/10
UPC
051712185295
Product Length/Depth
2 in
Product Height
0.56 in
Product Width
0.56 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
1.6 A
Interrupt rating
50 kAIC at 250 Vac 50 kAIC at 125 Vdc
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature: 1.6 A rating with a compact 2 inch length enables precise protection of low-current control circuits without nuisance trips. Business Impact: protects PLC inputs and sensors while minimizing unnecessary downtime and component wear. Application: instrumentation panels and analog signal conditioning in automation systems. Feature: 50 kA interrupt rating at both 250 Vac and 125 Vdc provides high fault-ride-out capability. Business Impact: reduces the risk of damage from short circuits and arc faults, improving manager-level risk management and maintenance planning. Application: protection for power supplies, motor control circuits, and automation starters in service cabinets. Feature: Class H, non-current-limiting fuse supports predictable coordination with other protection devices. Business Impact: enables simpler selectivity studies and lower coordination costs, supporting compliant panel design. Application: general purpose protection in electrical control panels. Feature: Non-indicating fuse with standard packaging of 10 units simplifies inventory and installation workflow. Business Impact: reduces stocking complexity and speeds replacement in field service. Application: routine maintenance and new builds requiring consistent Bussmann series compatibility. Feature: CE Marked, Bussmann Series compatibility, and RoHS-friendly considerations ease international procurement. Business Impact: accelerates global deployments and regulatory approvals, lowering project lead times. Application: multinational manufacturing lines and OEM integrations requiring standard components.
Get a Quick Quote for a Eaton NON-1-6/10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-1-6/10?
Enquire Now
FAQs
The fuse is rated for 1.6 A, with voltage ratings of 250 Vac and 125 Vdc, making it suitable for general control circuits in industrial panels and automation equipment. It is a non-current-limiting Class H device designed for continuous operation within its rated current.
The NON-1-6/10 fuse provides a 50 kAIC interrupt rating at both 250 Vac and 125 Vdc. This high interrupt capability protects equipment from severe fault currents, enabling safer electrical designs and reducing the risk of catastrophic component damage during short-circuit events.
This fuse is ideal for general protection in control panels, instrumentation, PLC inputs, sensors, and small drives where non-current-limiting protection is acceptable and reliable, consistent with Bussmann Class H devices. It offers straightforward procurement and compatibility within the Eaton Bussmann family.
The fuse measures 2 inches in length with 0.56 inches in width and height, and comes in standard packaging of 10 units. Its compact footprint simplifies installation in crowded panels and supports easy stocking and replacement in field service.
The NON-1-6/10 fuse is CE Marked, indicating conformity with European safety standards. It is compatible with the Bussmann Series Class H fuses, which helps ensure coordinated protection across devices in industrial control systems and supports RoHS considerations in compliant assemblies.
