Eaton NON-110 Fuse - Class H, 110A, 10 kAIC at 250V
Part Number: NON-110
Quick Summary
The Eaton NON-110 fuse is a general-purpose NON fuse designed to protect electrical circuits up to 110 A in panels, MCCs, and control cabinets. Engineers often contend with nuisance trips or under-protection when selecting fuses, which can cause costly downtime or equipment damage. This part carries CE marking and RoHS verification options via Eaton's RoHS search tool, ensuring regulatory alignment for compliant procurement. The Class H designation and Bussmann-series heritage support reliable, standard installation in modern industrial fleets, while the compact form and single-piece construction streamline stocking and field service. In short, it delivers predictable protection, reduced maintenance overhead, and a clear path to compliant, cost-efficient panel protection.
Product Information
Extended Description
NON-110 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 110 A, one-time fuse, interrupting rating of 10 kA at 250 Vac
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-110
UPC
051712301107
Product Length/Depth
7.13 in
Product Height
1.56 in
Product Width
1.56 in
Product Weight
0.8 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
110 A
Interrupt rating
10 kAIC at 250 Vac
Voltage rating
250 V
Packaging type
Standard
Class
Class H
Fuse indicator
Non-indicating
Quantity
1
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature: 110 A amperage rating combined with a 10 kAIC interrupt rating at 250 V. Business Impact: Provides robust protection for medium-size loads while limiting arc energy and shortening fault clearance times. Application: Ideal for general purpose protection in electrical panels and MCCs where reliable current handling is required. The result is improved equipment uptime and lower risk of damage from short circuits. Long-tail keywords: general purpose fuse, 110 A fuse, 10 kAIC at 250V, electrical protection in panels. Feature: Non-current-limiting (NON) and non-indicating design. Business Impact: Reduces nuisance operation indicators and simplifies status monitoring in dense control panels. Application: Suitable for non-limiting protection scenarios where precise arc-quenching isn’t required. This supports simpler installation and clearer labeling in complex cabinet assemblies. Long-tail keywords: non-current-limiting fuse, non-indicating fuse, panel labeling, fuse indicator absence. Feature: Class H construction with Bussmann-series compatibility. Business Impact: Ensures compatibility with standard Bussmann housings and inventory, minimizing redesign costs. Application: Suitable for replacement in existing Class H fuse architectures in control cabinets and power distribution panels. Long-tail keywords: Class H fuse, Bussmann-series compatibility, replacement in Class H architecture. Feature: Physical dimensions and packaging. Business Impact: The 7.13 in length and 1.56 in width/height enable fit in standard enclosures, reducing installation time. Application: Quick integration into established panel layouts, with straightforward stocking and ordering. Long-tail keywords: standard packaging, 7.13 in fuse, panel fit. Feature: Compliance and documentation. Business Impact: CE-marked product with RoHS verification options supports easy audit trails and regulatory compliance in procurement. Application: Ideal for regulated environments and organizations aiming to maintain supply-chain traceability. Long-tail keywords: CE Marked fuse, RoHS verification, regulatory compliance.
Get a Quick Quote for a Eaton NON-110
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-110?
Enquire Now
FAQs
Power down the panel and verify the catalog number NON-110. Use the appropriate Bussmann-series fuse holder, align the fuse with the contact terminals, and firmly seat it to ensure proper electrical contact. Confirm labeling and clearances meet panel standards before restoring power.
The NON-110 fuse provides a 10 kAIC interrupt rating at 250 VAC, with an amperage rating of 110 A. This combination supports reliable interruption of fault currents while protecting connected equipment.
Yes. It is a general-purpose, non-current-limiting Class H fuse designed for 110 A circuits in panels and MCCs. Ensure the non-current-limiting characteristic matches the protection strategy for the driven loads and coordination with upstream breakers.
The fuse is CE marked, indicating conformity with European health, safety, and environmental requirements. RoHS verification is available via Eaton’s RoHS search tool, helping procurement confirm material compliance in regulated environments.
Use the specified 110 A, 10 kAIC rating to guide replacement intervals and avoid overrating. Maintain an organized spare-fuse inventory, replace only with the same NON-110 Class H fuse, and document replacements to support asset management and uptime metrics.
