Eaton NON-12 Class H Fuse - 12 A, CE Marked for 50 kAIC
Part Number: NON-12
Quick Summary
Eaton NON-12 Class H fuse is a general-purpose protection device for control panels and industrial equipment. It delivers reliable overcurrent protection in compact form, helping engineers save panel space and simplify sourcing. This CE-marked Bussmann series fuse aligns with Class H expectations, providing predictable performance in a wide range of installations. The non-current-limiting design means it behaves predictably in circuits with inrush or startup surges, reducing nuisance outages when paired with appropriate protection schemes. For procurement and maintenance, the 10-pack packaging, ferrule-end connections, and straightforward interchangeability translate into lower total cost of ownership and faster uptime in demanding environments.
Product Information
Extended Description
NON-12 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 12 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-12
UPC
051712300087
EAN
5027590408073
Product Length/Depth
0.56 in
Product Height
2 in
Product Width
0.56 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
12 A
Interrupt rating
50 kAIC at 125 Vdc 50 kAIC at 250 Vac
Voltage rating
250 V
Packaging type
Standard
Class
Class H
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature: 12 A amperage rating with a 50 kAIC interrupt rating at 125 Vdc and 250 Vac. Impact: Enables robust protection for moderate-load circuits while minimizing the risk of catastrophic faults. Application: Suitable for general protection in control panels and power supplies where startup surges are manageable and fast clearing is required. Feature: Non-current-limiting design. Impact: Predictable fuse behavior in circuits with inrush, reducing nuisance outages and unnecessary maintenance. Application: Instrumentation panels and non-motor control circuits where inrush is anticipated. Feature: Ferrule-end x ferrule-end connections. Impact: Quick, secure mounting in Bussmann-compatible fuse blocks with reliable contact integrity. Application: Dense panel layouts and retrofit projects. Feature: Compact footprint (0.56 in W x 0.56 in D x 2 in H) and weight (0.35 lb). Impact: Saves panel space and simplifies shelving in cabinets. Application: High-density electrical enclosures and small control corridors. Feature: CE Marked compliance and Class H compatibility. Impact: Streamlines regulatory acceptance and cross-compatibility with Bussmann Class H families. Application: European installations and retrofit programs. Feature: Packaging type Standard and Quantity 10. Impact: Efficient procurement, reduced stockouts, and simplified replacement planning. Application: OEM assemblies and maintenance schedules. Feature: Special features Non current limiting. Impact: Clear specification for designers coordinating with other protective devices. Application: Systems requiring defined protection without aggressive current limitation.
Get a Quick Quote for a Eaton NON-12
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-12?
Enquire Now
FAQs
The NON-12 is a general-purpose, non-current-limiting fuse rated at 12 A with a 50 kAIC interrupt rating, designed for control panels, power supplies, and other general electrical protection needs in light-to-medium industrial environments. Its ferrule-end connections and compact form factor support quick, secure integration into Bussmann-compatible fuse blocks, helping reduce panel space and maintenance time.
As a non-current-limiting fuse, the NON-12 does not aggressively truncate inrush currents, which minimizes nuisance tripping in circuits with startup surges. This makes it suitable for systems where controlled startup is expected. It still provides robust fault protection with a 50 kAIC interrupt rating, ensuring safe interruption of short-circuit events when properly coordinated with other protection elements.
Yes, the NON-12 uses ferrule-end x ferrule-end connections, facilitating secure, tool-free installation in compatible fuse blocks. Its compact footprint (0.56 in W, 0.56 in D, 2 in H) supports dense panel layouts. Ensure correct alignment and tight ferrule connections to maintain rated performance and voltage integrity up to 250 V.
The NON-12 is CE marked, indicating compliance with European safety directives. It carries a 12 A amperage rating, a 50 kAIC interrupt rating at 125 Vdc and at 250 Vac, and a voltage rating of 250 V. Use it in circuits within these specifications, and in Bussmann Class H configurations that match your protection strategy.
Using the NON-12 in new equipment supports lower downtime due to robust, predictable protection and easy stocking with 10-fuse packs. The non-indicating design reduces front-panel maintenance needs, while the ferrule-end connections enable quick replacement in standard fuse blocks. The compact size and high interrupt rating contribute to safer fault clearance and a lower total cost of ownership over the equipment lifecycle.
