Eaton NON-2-1/2 Fuse - Class H Non-Current-Limiting
Part Number: NON-2-1/2
Quick Summary
Eaton NON-2-1/2 fuse provides general-purpose overcurrent protection for small control and power circuits in industrial panels. When a fuse is undersized or oversized, it can cause nuisance trips or insufficient protection, driving downtime. CE Marked compliance and Class H construction reinforce reliability, while the 50 kAIC interrupt rating at 125 Vdc and 250 Vac ensures robust fault handling. The device’s ferrule-end connections simplify installation, and its non-current-limiting design balances cost with predictable operation. By matching the 2.5 A rating to typical control circuits and referencing Bussmann’s full-line catalog, buyers gain predictable performance, easy replacements, and straightforward procurement for panel builders and OEMs.
Product Information
Extended Description
NON-2-1/2 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 2.5 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-2-1/2
UPC
051712300186
EAN
5027590408233
Product Length/Depth
0.56 in
Product Height
2 in
Product Width
0.56 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
2.5 A
Interrupt rating
50 kAIC at 125 Vdc 50 kAIC at 250 Vac
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature → Business Impact → Application: Class H, NON fuse with a 2.5 A rating delivers reliable, general-purpose protection for low-power control circuits; minimizes downtime by providing robust interruption capability up to 50 kAIC, while keeping replacement costs predictable in automation panels. Application: Suitable for machine control panels, small drives, and automation circuits where compact, standard fuses are required. Long-tail keywords addressed include Bussmann Class H fuses, non-current-limiting fuse, 2.5 A fuse, and 50 kAIC interrupt rating for mixed AC/DC environments.
Get a Quick Quote for a Eaton NON-2-1/2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-2-1/2?
Enquire Now
FAQs
The NON-2-1/2 is a Class H non-current-limiting fuse with ferrule-end x ferrule-end terminals designed for Bussmann Series holders and standard panel enclosures. It cross-references with Bussmann catalogs and fits common 0.56 in ferrule-terminals used in control panels, machine enclosures, and automation gear.
The fuse is rated at 2.5 A with an interrupt rating of 50 kAIC, and it supports voltage ratings of 250 Vac and 125 Vdc. This combination provides reliable protection for low-power control circuits while handling large fault currents when required.
Yes. The fuse is rated for 125 Vdc and 250 Vac, with 50 kAIC interrupt capacity. When used in DC applications, ensure system voltage and fault currents stay within the 125 Vdc rating and follow standard safety practices for DC fusing.
The fuse measures 0.56 inches in length and width, is 2 inches tall, and weighs about 0.35 lb. It is packaged in standard packaging with a quantity of 10 per pack, and features ferrule-end terminations for straightforward installation.
This fuse is CE-marked, indicating conformity with European standards. It is a non-indicating device in the Bussmann series and uses Class H construction for reliable general-purpose protection in industrial panels.
