Eaton NON-20 Fuse - CE Marked Class H Non-current Limiting
Part Number: NON-20
Quick Summary
The Eaton NON-20 fuse provides reliable circuit protection for general-purpose electrical panels and control circuits. Engineers often struggle with selecting fuses that balance protective speed, uptime, and replacement costs in demanding industrial environments. This Class H, non-current-limiting fuse is CE marked and rated for 20 A with a 50 kAIC interrupt rating at 125 Vdc and 250 Vac, supporting robust safety and reliability. For panel builders and maintenance teams, the compact ferrule-end design and standardized packaging simplify installation and spare-part management. Note that SIL or IP ratings are not specified for this item, so verify your application requirements against the datasheet. The 2 inch length and slim profile help maximize space and ease procurement in crowded control panels.
Product Information
Extended Description
NON-20 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 20 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-20
UPC
051712101578
Product Length/Depth
2 in
Product Height
0.56 in
Product Width
0.56 in
Product Weight
0.036 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
20 A
Interrupt rating
50 kAIC at 125 Vdc 50 kAIC at 250 Vac
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature: Amperage and interrupt rating of 20 A with a 50 kAIC interrupt rating at 125 Vdc and 250 Vac. Business Impact: Provides robust short-circuit protection with clear coordination for typical industrial loads, reducing unexpected downtime and equipment damage. Application: Suitable for general-purpose control panels and industrial machinery where a 20 A protection level is appropriate. Feature: Non-current-limiting (NON) design. Business Impact: Predictable fusing behavior that avoids unnecessary upstream current limiting, allowing inrush or startup conditions to proceed without premature fuse operation. Application: Applications where controlled inrush is expected, such as control relays and simple motor circuits. Feature: Class H with ferrule end x ferrule end connections. Business Impact: Easy, secure installation with standard ferrule terminations, enabling reliable contact and reduced field wiring complexity. Application: Panel wiring harnesses and compact control enclosures. Feature: Compact form factor (2 in length, 0.56 in width, 0.56 in height) and light weight (0.036 lb). Business Impact: Space-saving design supports dense panel layouts and simpler stocking with higher part density. Application: Modern control panels where space is at a premium. Feature: Packaging type Standard and Quantity 10. Business Impact: Streamlined procurement and predictable spares availability for maintenance cycles. Application: Warehouse stocking and field service readiness. Feature: Compliance and indications. Business Impact: CE Marked provides regulatory alignment for many global markets; non-indicating fuse reduces visual clutter in panels. Application: Panels requiring straightforward compliance and minimal status indicators.
