Eaton NON-45 Fuse - CE Marked, 50 kAIC
Part Number: NON-45
Quick Summary
Eaton NON-45 fuse is a general-purpose protection device for control circuits and equipment. It delivers reliable, one-time protection in industrial panels, MCCs, and similar installations. The fuse carries CE Marking and offers a robust 50 kAIC interrupt rating at 125 Vdc and 250 Vac, with a 45 A rating to suit standard protection needs. Its standard packaging and ferrule-end connections simplify stocking and field replacement. For procurement, this fuse aligns with Bussmann series protections, reducing downtime and inventory complexity while supporting safe, compliant operation across multiple applications.
Product Information
Extended Description
NON-45 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 45 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-45
UPC
051712101622
Product Length/Depth
0.81 in
Product Height
3 in
Product Width
3 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
45 A
Interrupt rating
50 kAIC at 125 Vdc 50 kAIC at 250 Vac
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Low Voltage Branch Circuit Fuse Chapter
Low Voltage Branch Circuit Fuse Chapter
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature → Business Impact → Application: General-purpose Class H NON fuse provides dependable protection for control circuits, reducing nuisance trips and maintenance costs in machine bays and panels. This translates to improved uptime and predictable service intervals in automation systems. Application: Control panels, PLC rack feeds, and small motor circuits requiring reliable 45 A protection with straightforward, ferrule-end wiring. Feature → Business Impact → Application: Non-current-limiting design preserves circuit behavior for certain inductive loads, enabling safer inrush handling and easier coordination with upstream protection. Application: Conveyor drives, feed lines in packaging lines, and machine tool controllers where precise coordination matters. Feature → Business Impact → Application: 50 kAIC interrupt rating at 125 Vdc and 250 Vac provides strong fault clearance, minimizing arc energy and equipment damage during faults. Application: Main feeders, MCC sections, and protective interlocks inside power distribution enclosures. Feature → Business Impact → Application: Ferrule end x ferrule end connections enable fast, secure terminations with compatible bus bar or terminal block hardware. Application: Quick swaps on serviceable panels and retrofit projects requiring minimal rewiring. Feature → Business Impact → Application: Standard packaging of 10 pieces supports efficient stocking and reordering for maintenance teams. Application: Stocking in repair spares kits for production lines and industrial facilities.
Get a Quick Quote for a Eaton NON-45
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-45?
Enquire Now
FAQs
Install the NON-45 with ferrule-end connections into compatible terminal blocks or fuse holders designed for Class H Bussmann fuses. Ensure the circuit voltage does not exceed 250 Vac, and verify a 45 A rating matches the protected load. Use proper de-energization and follow lockout/tagout procedures during replacement to prevent arc and shock hazards.
The NON-45 fuse provides a 50 kAIC interrupt rating at 125 Vdc and 250 Vac. This makes it suitable for general-purpose protection in control panels, small motor feeders, and automation circuits where high energy faults could occur and rapid, safe interruption is required.
Yes, as long as the operating voltage remains within the rated 125 Vdc maximum. The 24 Vdc circuits fall well within the 125 Vdc rating, making the NON-45 appropriate for many low-voltage control applications while maintaining the 45 A protection and 50 kAIC interrupt capability.
The NON-45 fuse is CE Marked, indicating compliance with applicable European electrical safety and performance standards. For verification, reference Eaton’s documentation and the CE marking on the product packaging; use Eaton’s RoHS and compliance tools if needed to confirm current status across your locale.
With a 10-piece packaging and standard Bussmann form factor, stocking and reordering are straightforward for maintenance teams. Its non-indicating status reduces cost and complexity, while the 50 kAIC rating and 45 A capacity deliver reliable protection with minimized downtime, improving overall ROI in automated facilities.
