Eaton NON-6-1/4 Fuse - CE Marked Class H, 50 kAIC
Part Number: NON-6-1/4
Quick Summary
Eaton Bussmann NON fuse provides non-current-limiting protection for general‑purpose circuits in industrial equipment. Users often confront nuisance trips or mismatched protection that cause unplanned downtime during startups and load changes. This device carries CE Marking and Bussmann Class H classification, with an interrupt rating of 50 kAIC at 125 Vdc and 250 Vac, ensuring fast, dependable fault interruption. Designed for motor controllers, control panels, and power distribution blocks, it delivers reliable protection while enabling straightforward stocking and routine maintenance. The 6.25A rating suits small to medium loads, and the compact 0.56 in depth with a 2 in height helps engineers fit into tight enclosures. With non‑current‑limiting behavior and a 10‑pack per order, procurement teams can optimize spares and reduce downtime.
Product Information
Extended Description
NON-6-1/4 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 6.25 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-6-1/4
UPC
051712185431
EAN
5027590173940
Product Length/Depth
0.56 in
Product Height
2 in
Product Width
0.56 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
6.25A
Interrupt rating
50 kAIC at 125 Vdc 50 kAIC at 250 Vac
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature 6.25A amperage rating → Business Impact Protects the circuit while minimizing nuisance trips during normal operation; Application Ideal for small to medium loads in control panels and sensor circuits. Feature 50 kAIC interrupt rating at 125 Vdc and 250 Vac → Business Impact Provides high fault current protection, enhancing overall system safety and reducing exposure to arc-flash events; Application Suitable for power distribution blocks and motor controller feeds in medium-risk environments. Feature Class H, CE Marked → Business Impact Ensures regulatory compliance and compatibility with European and global safety standards; Application Fits standard Bussmann Class H fuse holders and compliant enclosure designs. Feature Non-indicating design → Business Impact Simplifies replacement in dense installations and reduces nuisance indicators in panel diagnostics; Application Useful in control cabinets with limited status indicators. Feature Packaging quantity of 10 → Business Impact Streamlines maintenance logistics and spare-part management; Application Supports service teams in multi-site deployments. Feature Dimensions 0.56 in length/depth, 0.56 in width, 2 in height with 0.35 lb weight → Business Impact Enables compact installation in tight enclosures and lightweight handling during field replacements; Application Ideal for compact control panels and retrofit projects. Feature General information including 250 Vac / 125 Vdc ratings → Business Impact Delivers predictable protection across dual-voltage systems; Application Suitable for mixed-voltage equipment in industrial environments.
Get a Quick Quote for a Eaton NON-6-1/4
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-6-1/4?
Enquire Now
FAQs
The NON-6-1/4 fuse is designed for Bussmann Series Class H protection applications and fits standard Bussmann Class H holders used in control panels and power distribution blocks. When replacing an existing fuse, verify the holder’s ratings match 6.25A and the dual-voltage capability (250 VAC / 125 VDC) to ensure safe operation and reliable interruption during faults.
Key ratings include a 6.25A amperage rating, an interrupt rating of 50 kAIC at 125 VDC and 250 VAC, and voltage ratings of 250 VAC and 125 VDC. The fuse is classified as Class H and is CE marked, with a non-current-limiting behavior suitable for general-purpose protection in many industrial circuits.
Recommended for general-purpose protection in motor controllers, control panels, and power distribution blocks within industrial equipment. Its non-current-limiting design helps avoid nuisance trips during normal startup surges, while its high interrupt rating provides robust protection for higher fault currents common in industrial settings.
The fuse carries CE Marking and belongs to Bussmann Class H family, aligning with European and international safety standards. This certification simplifies compliance for multi-site deployments and supports regulatory approvals for machines assembled in or shipped to CE-mark regions, improving vendor reliability and customer confidence.
Maintenance benefits come from predictable performance and easy spares management, with a packaging quantity of ten per order simplifying inventory. The non-current-limiting design reduces nuisance trips, potentially lowering downtime during routine operation and startup, while the robust 50 kAIC rating provides strong fault protection that can minimize costly equipment damage.
