Eaton NON-75 Fuse - Class H, 75 A, 10 kAIC at 250 Vac
Part Number: NON-75
Quick Summary
Eaton Bussmann NON-75 fuse provides general-purpose circuit protection for industrial control panels. This fuse guards electrical circuits against overcurrent events by interrupting faults, reducing downtime and protecting costly equipment. In practice, engineers rely on a non-current-limiting design when coordination with upstream protection and selectivity is essential, making this device ideal for legacy systems and older panel architectures. With CE marking and RoHS information available via Eaton's RoHS search tool, regulatory alignment across regions becomes easier to confirm. The NON-75 also benefits from standard Bussmann Class H form-factor compatibility and a compact 5.88 in length, supporting easier installation in crowded enclosures. For buyers seeking reliable, widely supported protection, this fuse offers solid performance with straightforward replacement.
Product Information
Extended Description
NON-75 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 75 A, one-time fuse, interrupting rating of 10 kA at 250 Vac and 10 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-75
UPC
051712185479
Product Length/Depth
5.88 in
Product Height
1.06 in
Product Width
1.06 in
Product Weight
0.3 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
75 A
Interrupt rating
10 kAIC at 250 Vac 50 kAIC at 125 Vdc
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Fuse indicator
Non-indicating
Quantity
5
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature 75 A amperage rating → Business Impact Provides solid overcurrent protection for main feeders and control circuits, reducing the risk of component damage and unscheduled downtime. Application Suitable for general-purpose protection in industrial panels and machines, with compatibility to Bussmann Class H holders. Long-tail keywords: 75 A fuse, general purpose fuse, industrial protection. Feature 10 kAIC at 250 Vac; 50 kAIC at 125 Vdc → Business Impact High fault-current withstand capacity ensures safe interruption in power distribution blocks and motor starters, supporting compliance with panel design standards. Application Ideal for larger loads where higher short-circuit energy is anticipated. Long-tail keywords: high interrupt rating fuse, 250 Vac, 125 Vdc. Feature Non-current-limiting design → Business Impact Reduces nuisance tripping in selectivity-focused circuits, enabling coordinated protection schemes and fewer unnecessary outages. Application Suitable for legacy equipment and systems requiring predictable fuse behavior. Long-tail keywords: non-current-limiting fuse, selectivity, legacy systems. Feature Class H physical form factor → Business Impact Streamlines installation with compatible holders and enclosures, minimizing retrofit costs. Application Fits standard Bussmann Class H holders in control panels and distribution enclosures. Long-tail keywords: Class H fuse, Bussmann Class H, enclosure compatibility. Feature CE Marked and RoHS information available → Business Impact Ensures regulatory compliance across regions, easing procurement and quality audits. Application Supports global product deployment and supplier qualification. Long-tail keywords: CE marking, RoHS compliance, regulatory compliance. Feature 5-piece standard packaging → Business Impact Facilitates stocking and quick-replacement workflows in maintenance environments. Application Enables efficient purchasing for panel shops and service teams. Long-tail keywords: standard packaging, spare fuse kits, maintenance readiness.
Get a Quick Quote for a Eaton NON-75
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-75?
Enquire Now
FAQs
The NON-75 fits standard Bussmann Class H fuse holders and is sized for a 5.88 in length with 1.06 in width and height, enabling straightforward installation in common control panels and distribution enclosures.
The fuse is rated for 75 A, with voltage ratings of 250 Vac and 125 Vdc. Its interrupt ratings are 10 kAIC at 250 Vac and 50 kAIC at 125 Vdc, classifying it as a robust general-purpose, non-current-limiting device.
The NON-75 is a non-current-limiting fuse intended for general protection; it supports 125 Vdc but is not optimized for high inrush suppression. For circuits with frequent high inrush, consider a current-limiting alternative or detailed coordination with upstream protection.
The fuse is CE Marked, signaling EU compliance, and Eaton provides RoHS compliance information via its RoHS search tool to support regulatory reviews for multi-region deployments.
As a one-time fuse, it should be replaced after a fault occurrence. The product ships in standard packaging (5 pieces), facilitating stocking for maintenance teams and minimizing downtime during replacement.
