Eaton NON-9 Fuse - Class H, 9 A, 50 kAIC
Part Number: NON-9
Quick Summary
Eaton NON-9 fuse provides reliable non-current-limiting protection for general-purpose circuits in industrial controls. When downtime matters and panel space is at a premium, you need a fuse that is easy to source, spec, and replace. This Class H, non-indicating fuse is CE marked for European compliance and pairs with Bussmann series data sheets for fast, accurate selection. In practice, you gain reliability, predictable protection, and clearer procurement with a known 9 A rating and a 50 kAIC interrupt rating. Designed for general protection in electrical protection and circuit control applications across automation panels.
Product Information
Extended Description
NON-9 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 9 A, one-time fuse, interrupting rating of 50 kA at 250 Vac and 50 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-9
UPC
051712185516
Product Length/Depth
2 in
Product Height
0.56 in
Product Width
0.56 in
Product Weight
0.35 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
9 A
Interrupt rating
50 kAIC at 125 Vdc 50 kAIC at 250 Vac
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Fuse indicator
Non-indicating
Quantity
10
Special features
Non current limiting
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature: 9 A amperage rating with a non-current-limiting (NON) design. Business Impact: Enables normal inrush handling without nuisance tripping, reducing unnecessary downtime and service calls. Application: Ideal for general purpose protection in automation and control panels. Feature: High interrupt rating of 50 kAIC at 125 Vdc and 250 Vac. Business Impact: Ensures rapid fault isolation, protecting downstream components and reducing arc exposure during short circuits. Application: Critical power paths in machine controls and panelboards. Feature: Class H fuse construction with non-indicating indicators. Business Impact: Standardized form factor and maintenance-friendly replacement without visual indicators, simplifying stock and servicing. Application: Control consoles and compact electrical cabinets. Feature: Non-indicating, standard packaging. Business Impact: Streamlines procurement and reduces field ambiguity during replacement; ships in consistent packs for inventory planning. Application: OEM and aftermarket panel assembly in manufacturing environments. Feature: One-time fuse design with Bussmann series compatibility. Business Impact: Delivers definitive protection with predictable lifecycle; minimizes reuse risk in fault conditions. Application: Single-use protection in distributed control systems and automation equipment.
Get a Quick Quote for a Eaton NON-9
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-9?
Enquire Now
FAQs
The Eaton NON-9 fuse is designed for general-purpose protection in electrical protection and circuit control circuits within industrial automation. With a 9 A rating and a 50 kAIC interrupt capacity, it is ideal for controlling motors, power supplies, and automation logic within standard control panels while maintaining reliable fault isolation and predictable replacement cycles.
As a non-current-limiting fuse, the NON-9 allows inrush currents typical to control circuits to pass without immediate current restriction. This reduces nuisance tripping during startup surges, provided the inrush remains within the panel’s protected design limits. For applications with large startup transients, verify inrush compatibility against the circuit’s total impedance and transformer characteristics.
Yes. The NON-9 is CE marked, indicating compliance with applicable European safety and conformity directives. It is designed for broad industrial use and aligns with Bussmann series data and standard protection practices, supporting regulatory requirements in many regions.
Key specs include a 9 A amperage rating; 50 kAIC interrupt rating at both 125 Vdc and 250 Vac; voltage ratings of 250 Vac and 125 Vdc; and a Class H, non-indicating design. This combination supports reliable circuit protection in standard automation and electrical protection applications.
The fuse measures 2 inches in length with a width and height of 0.56 inches, and weighs about 0.35 lb. It ships in standard packaging with a quantity of 10 units per pack, making it straightforward to stock and replace in control panels.
