Eaton Bussmann NON-90 Fuse - CE Marked Class H
Part Number: NON-90
Quick Summary
NON-90 fuse by Eaton Bussmann is a general-purpose Class H fuse that protects electrical circuits up to 90 A in 250 Vac or 125 Vdc systems. This solution helps prevent costly downtime by interrupting faults quickly while minimizing nuisance trips in nominal loads. The device is CE Marked and designed for compatibility with Bussmann Class H blade-end fuse holders, supporting reliable interchange across Eaton’s fuse family. For engineers facing tight enclosure space and quick replacement needs, the NON-90 offers a compact 1.6 in depth and 5.88 in height packaging, while delivering predictable performance. It also aligns with safety and regulatory expectations, delivering total cost of ownership benefits through durability and easy stocking.
Product Information
Extended Description
NON-90 Eaton: Eaton Bussmann Series Class K5 fuse, NON, general purpose, non-current-limiting fuses, 90 A, one-time fuse, interrupting rating of 10 kA at 250 Vac and 10 kA at 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
NON-90
UPC
051712101677
EAN
5027590408141
Product Length/Depth
1.6 in
Product Height
5.88 in
Product Width
1.6 in
Product Weight
0.3 lb
Warranty
Not Applicable
Compliances
CE Marked
Amperage Rating
90 A
Interrupt rating
10 kAIC at 250 Vac 50 kAIC at 125 Vdc
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard
Class
Class H
Connection
Blade end x blade end
Fuse indicator
Non-indicating
Quantity
5
Special features
Pin-indicating
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
Bussmann series Class H (K) Fuses Data Sheet no. 1030
Feature → Business Impact → Application: The NON-90 delivers a 90 A amperage rating with a high interrupt rating of 10 kAIC at 250 Vac and 50 kAIC at 125 Vdc, enabling fast fault interruption and reduced downtime in control panels and power distribution. This translates to improved equipment reliability and lower maintenance costs, especially in high-load industrial environments where permission to tolerate brief overcurrents is limited. Application-wise, it fits general-purpose circuits in machinery, enclosures, and panelboards that require dependable protection without current limiting, allowing smooth operation under nominal loads while preserving downstream components. Feature → Compatibility → Installation: Blade end x blade end connections align with standard Class H fuse holders and Bussmann cataloging, enabling rapid stocking and straightforward retrofits. This minimizes installation time and inventory complexity in maintenance shops and manufacturing lines, while the 5-per-pack packaging aids warehousing efficiency. Feature → Compliance → Risk management: CE marking ensures compliance with EU safety standards, reducing regulatory risk during audits and simplifying cross-border deployments. Pin-indicating capability (where available) supports quick status checks during inspections and servicing, reducing the risk of undetected fuse faults and unplanned downtime.
Get a Quick Quote for a Eaton NON-90
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton NON-90?
Enquire Now
FAQs
The NON-90 uses blade end x blade end connections designed for standard Bussmann Class H fuse holders. It fits common panelboard and control enclosure DIN rail or block styles that accept Class H fuses. Verify enclosure space and clearance for the 1.6 in depth by 5.88 in height footprint and ensure the holder supports non-current-limiting, non-indicating fuses.
The NON-90 is rated for 90 A and accommodates voltage ratings of 250 Vac and 125 Vdc. It provides an interrupt rating of 10 kAIC at 250 Vac and 50 kAIC at 125 Vdc, making it suitable for protecting general-purpose circuits in mixed AC/DC environments while maintaining fast fault clearance.
Yes, the NON-90 is a general-purpose, non-current-limiting Class H fuse intended for protection of standard control circuits and general panel protection. It is not designed for motor protection where current-limiting or time-delay characteristics are required; for those applications, a motor-rated fuse or contactor coordination may be more appropriate.
The NON-90 carries CE marking indicating compliance with applicable European safety standards. While CE is the primary certification listed, Eaton also provides tooling and resources for RoHS compliance verification for this product family, supporting regulatory alignment across markets.
Using the NON-90 can reduce downtime due to its reliable fault interruption and straightforward replacement in standard Class H fuse blocks. The 5-count packaging simplifies inventory management, and the compact form factor supports easier service access in tight panels. Overall, you gain predictable maintenance intervals, straightforward sourcing from Eaton’s Bussmann line, and lower total cost of ownership.
