Eaton PBC6 Push Button Enclosure - Surface Mount, NEMA 12
Part Number: PBC6
Quick Summary
The Eaton PBC6 push button enclosure protects control circuits in industrial panels. This compact, surface-mounted enclosure fits tight spaces and speeds installation while delivering reliable access for wiring and maintenance. Featuring a NEMA 12 rating, carbon steel construction with a 14 gauge wall and an oil-resistant gasket, it stands up to dusty and splashed environments. Painted ANSI 61 gray and with external mounting feet, it offers durable, low-maintenance operation. Originating in the US, the PBC6 supports standard control-panel modernization and easy integration into B-Line enclosures and automation infrastructure.
Product Information
Extended Description
PBC6 Eaton: Eaton B-Line series push button enclosures, 6.25" height, 6.37" length, 9.5" width, NEMA 12, Hinged cover, PBC enclosure, Surface mounted, Small single door, External mounting feet, Carbon steel, Oil-resistant gasket
Product Name
Eaton B-Line series push button enclosures
Catalog Number
PBC6
UPC
782051701661
Product Length/Depth
6.37 in
Product Height
6.25 in
Product Width
9.5 in
Product Weight
7.1 lb
Compliances
Not Applicable
Certifications
Not Applicable
Material
Carbon steel
Wall thickness
14 gauge
Finish color
Painted
Color
ANSI 61 gray
Style
Small single door
Model
PBC enclosure
Cover type
Hinged
Mounting method
Surface
Mounting hole details
External mounting feet
Closure type
Hinged
Special features
Removable cover, recessed pull ring, plated screws
NEMA Rating
12
Country of origin
US
NEMA 12 protection and 14 gauge carbon steel construction shield sensitive control components from dust, splashes, and grime, delivering measurable uptime improvements and extended service life for industrial panels. The design blends surface mounting with external mounting feet to simplify installation in compact spaces, reducing field labor and commissioning time. A hinged, removable cover plus recessed pull ring speeds wiring, inspection, and maintenance while minimizing downtime and exposure to contaminants. The ANSI 61 gray finish and oil-resistant gasket enhance durability in harsh environments, lowering repaint and gasket-replacement costs over the enclosure’s life. Compatibility with Eaton’s B-Line family enables rapid panel upgrades, interchangeability with existing components, and predictable spare-part planning for automation projects. Industry practitioners value the combination of rugged protection, ease of access, and clear total-cost-of-ownership benefits.
Get a Quick Quote for a Eaton PBC6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PBC6?
Enquire Now
FAQs
The PBC6 is designed for surface mounting with external mounting feet, enabling fast integration into existing control panels. Its hinged cover provides rapid access for wiring and maintenance, while the removable cover and recessed pull ring support quick panel commissioning. Ensure mounting is level and supports the 7.1 lb weight for safe, vibration-free operation in machines and process lines.
Core specifications include a NEMA 12 rating, carbon steel construction with a 14 gauge wall, and an oil-resistant gasket. Dimensions are 6.25 in height, 6.37 in depth, and 9.5 in width. The enclosure is painted ANSI 61 gray and weighs 7.1 lb, providing durable protection for control components in dusty or damp environments.
Yes for environments requiring dust, splash, and grime resistance thanks to the NEMA 12 rating and oil-resistant gasket. While catalog data emphasizes the NEMA protection level and rugged carbon steel construction, it does not list additional certifications like CE or SIL. It is well-suited for rugged shop floors and machine rooms where robust control enclosures are needed.
External mounting feet and surface-mount capability simplify field installation in tight spaces, reducing labor and mounting complexity. The hinged, removable cover facilitates quick wiring access and faster maintenance. Its compatibility with the Eaton B-Line series supports streamlined upgrades and spare-part planning, helping maintain project schedules and minimize downtime during panel refurbishments.
Consider maintenance savings from reduced downtime due to quick access features, improved reliability from a weather-protected, dust-resistant enclosure, and faster commissioning enabled by the removable cover and straightforward mounting. The durable carbon steel construction and oil-resistant gasket lower long-term replacement costs, while compatibility with existing B-Line components simplifies upgrades and spare-part stocking.
