Eaton PBC8 Push Button Enclosures - NEMA 12 Rating
Part Number: PBC8
Quick Summary
Eaton PBC8 push button enclosures protect control panels in industrial automation. They address common installation challenges by offering a compact, surface‑mount solution with a hinged cover and removable features for quick servicing. Designed for NEMA 12 protection and manufactured in the US, they pair 14‑gauge carbon steel with an ANSI 61 gray painted finish for dependable, long‑term use. In practice, this translates to faster panel assembly, easier maintenance, and consistent protection across machines. For integrators and OEMs, the combination of robust construction and simplified access directly supports higher up‑time and lower lifecycle costs.
Product Information
Extended Description
PBC8 Eaton: Eaton B-Line series push button enclosures, 6.25" height, 6.37" length, 11.75" width, NEMA 12, Hinged cover, PBC enclosure, Surface mounted, Small single door, External mounting feet, Carbon steel, Oil-resistant gasket
Product Name
Eaton B-Line series push button enclosures
Catalog Number
PBC8
UPC
782051701678
Product Length/Depth
6.37 in
Product Height
6.25 in
Product Width
11.75 in
Product Weight
8.3 lb
Compliances
Not Applicable
Certifications
Not Applicable
Material
Carbon steel
Wall thickness
14 gauge
Finish color
Painted
Color
ANSI 61 gray
Style
Small single door
Model
PBC enclosure
Cover type
Hinged
Mounting method
Surface
Mounting hole details
External mounting feet
Closure type
Hinged
Special features
Removable cover, recessed pull ring, plated screws
NEMA Rating
12
Country of origin
US
Feature: Surface mounting with external mounting feet enables quick, stable installation on uneven or existing surfaces. Business Impact: Reduces installation time and allows reuse of established footprints, cutting project labor costs. Application: Machine control panels and process enclosures where mounting space is constrained. Feature: 14 gauge carbon steel with a 14 gauge wall and ANSI 61 gray painted finish provides durable protection against handling and minor impacts. Business Impact: Improves enclosure longevity in harsh environments, lowering replacement frequency and maintenance downtime. Application: Factory floors, dusty or oily environments common in manufacturing settings. Feature: NEMA 12 rating with a hinged, external‑mounting, small single door design and removable cover. Business Impact: Ensures reliable interior protection while allowing fast access for wiring and diagnostics, reducing commissioning and service time. Application: Control circuits, motor starters, and safety interlocks in panel assemblies. Feature: Removable cover, recessed pull ring, and plated screws support straightforward servicing and reconfiguration. Business Impact: Simplifies field maintenance and re‑termination, improving technician efficiency and reducing error‑prone rework. Application: Panels requiring routine access for testing or upgrades. Feature: Compatibility with Eaton B‑Line series and surface mounting with external feet. Business Impact: Streamlines component matching and spare-part inventory, enabling scalable panel designs across multiple machines. Application: OEM panel shops and modernization programs with standardized enclosures.
Get a Quick Quote for a Eaton PBC8
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton PBC8?
Enquire Now
FAQs
The PBC8 uses surface mounting with external mounting feet, allowing installation on flat or uneven surfaces. Install by aligning the enclosure with the mounting points, securing with the provided fasteners, and then routing wiring through the hinged cover entry. The external feet simplify leveling and alignment at the panel face, reducing field adjustment time.
PBC8 measures 6.25 in in height, 6.37 in in depth, and 11.75 in in width, weighs approximately 8.3 lb, and uses 14 gauge carbon steel with ANSI 61 gray paint. It is rated to NEMA 12, has a hinged cover, surface mounting, and external mounting feet for robust protection in industrial environments.
PBC8 is rated NEMA 12, which covers protection against dust and non‑solvent dripping water in indoor environments. It is not specified as IP rated for direct outdoor exposure. For outdoor applications or washdown areas, consider enclosures with IP ratings or additional weatherproofing accessories.
The hinged cover and removable cover features allow rapid access for wiring and diagnostics, while external mounting feet simplify mounting alignment. The oil‑resistant gasket protects interior components from incidental exposure to lubricants or moisture. These design elements collectively reduce field downtime during servicing and upgrades.
PBC8 is part of Eaton’s B‑Line family, which streamlines compatibility with other enclosure, mounting, and control components. This standardization reduces spare‑part inventories, speeds assembly, and improves maintenance predictability, delivering lower total cost of ownership across multiple machines and control panels.
